Explore Displays for Real Projects

If you have ever bought the wrong displays, you know how annoying it feels. You will find options here that work well for beginners as well as people building serious projects. Take your time, look around, and choose the displays that fits your project best.

Buy Display Module Online in India

A display module is an LED or LCD screen that represents the output picture to the user and also sometimes provides a touch screen for user interaction. A display module is defined as a highly integrated real-time embedded system that is tuned to efficiently interact and communicate with the environment.

Do you need a display for your project? You can put an end to your search right here. As a leading robotics part supplier in INDIA, we stock a wide range of display types including, Arduino & Raspberry Pi display modules, IoT display module, 7-segment display module, HDMI display modules with varying sizes and technical parameters.

Display Modules are compatible with Arduino, Raspberry Pi, some sensors to know the readings, other development boards and more

DIY Projects Using Displays

Smart Clock / Digital Clock : Combine RTC module + OLED/LCD display to show time, date, alarms.
Weather Station : Use temperature, humidity, and pressure sensors to display real-time weather data on OLED/TFT screens.
Home Dashboard : Show WiFi status, room temperature, notifications, and IoT data using an ESP32 + color TFT display.
Sensor Data Console : Display distance, gas levels, or motion data on a compact LCD/OLED screen for robotics projects.
Mini Gaming Console : Use small OLED/TFT screens to create retro-style games for fun STEM learning.
Scoreboard / Counter : Use 7-segment LED displays for score tracking, counters, or timers in competitions.

Wiring & Code Tutorials for Popular Display Types

16×2 LCD (I2C)

Wiring (I2C version):

VCC → 5V
GND → GND
SDA → A4
SCL → A5

Basic Arduino Code:

#include <LiquidCrystal_I2C.h>
LiquidCrystal_I2C lcd(0x27, 16, 2);

void setup() {
  lcd.begin(16, 2);
  lcd.print("Hello Robocraze!");
}

void loop() {}

OLED Display (SSD1306 I2C)

Wiring:

VCC → 3.3V / 5V
GND → GND
SDA → A4
SCL → A5

Basic Arduino Code:

#include <Adafruit_GFX.h>
#include <Adafruit_SSD1306.h>

Adafruit_SSD1306 display(128, 64, &Wire);

void setup() {
  display.begin(SSD1306_SWITCHCAPVCC, 0x3C);
  display.clearDisplay();
  display.print("Hello!");
  display.display();
}

void loop() {}

7-Segment LED Display (TM1637)

Wiring (TM1637):

CLK → D2
DIO → D3
VCC → 5V
GND → GND

Basic Arduino Code:

#include <TM1637Display.h>

TM1637Display disp(D2, D3);

void setup() {
  disp.showNumberDec(1234);
}

void loop() {}

4. TFT LCD (SPI)

Wiring:

VCC → 5V
GND → GND
CS → D10
RST → D8
DC → D9
MOSI → D11
SCK → D13

Basic Arduino Code:

#include <Adafruit_GFX.h>
#include <Adafruit_ILI9341.h>

Adafruit_ILI9341 tft(10, 9);

void setup() {
  tft.begin();
  tft.setCursor(10, 10);
  tft.print("Robocraze TFT!");
}

void loop() {}

LCD vs OLED vs LED Display Comparison

Display Type	Pros	Cons	Best Use Case
LCD (16×2, 20×4)	Cheap, easy to use, great for text	Limited graphics, lower contrast	Basic dashboards, counters, simple menus
OLED (128×64)	High contrast, sharp text/graphics, low power	Small size, slightly higher price	Wearables, small IoT devices, sensor displays
LED (7-segment / matrix)	Bright, great for numbers, simple	Not good for complex graphics	Clocks, counters, timers, scoreboards
TFT LCD (Color)	Supports images & full graphics	More wiring, uses more power	Smart dashboards, games, camera display, GUIs

Different types of display modules:

1. OLED Display Module:

OLED Display module (organic light-emitting diode), is a self-light-emitting technology that is composed of a thin, multi-layered organic film that is placed between the anode and cathode. In contrast with LED technology, OLED does not require a backlight for displaying the output. OLEDs are used in home electronic module displays.

2. LCD Display Module:

An LCD display module (Liquid crystal display) is an electronic display module that uses liquid crystals to produce an image. Unlike OLED technology, they require a backlight to illuminate the display on the screen.

3. Arduino display module:

Arduino display allows communication with alphanumeric liquid crystal displays (LCD). Here we accept serial input from the computer and upload the sketch to Arduino. The characters will be displayed on the LCD.

4. LED Display Module:

An LED display module is a small screen that includes an LED and the rest of the necessary electronics so that it can reproduce images and videos. They are used in audiovisual display visual impact production. They are light and accessible, they produce good resolution and their contrast ratio is unmatchable.

5. Paper Display:

A paper display or electronic paper display (EDP) is an electrically charged surface that replicates the look and experience of ink on the paper. They only require power when a new image is requested. Instead of a traditional display that uses backlighting to illuminate pixels, an EDP is based on a phenomenon called electrophoresis.

6. TFT LCD Display:

The TFT LCD display module is a type of liquid crystal display. The TFT Display uses a thin film transistor technology and it improves qualities like contrast and accessibility. This TFT refreshes more quickly than a monochrome LED screen. Due to this feature, they generally cost more than LED or LCD screens.

7. Accessory Display:

At Robocraze, we have different display accessories for LED, LCD, and OLED displays. We offer an Acrylic Case Shell for DIY Oscillator Kit. This is greatly designed for oscilloscope and this can efficiently protect the meter. We also offer a 7-inch universal tablet flip cover with a keyboard.

Display Module Prices in India

Sr. No.	Product	Price Range
1	LCD Display Modules	Rs.67 to Rs.7314
2	OLED Display Modules	Rs. 13 to Rs.520
3	TFT Display Modules	Rs.313 to Rs.2068
4	7 Segment Display Module	Rs.8 to Rs. 2268
5	E-Ink Display Module	Rs.3669 to Rs.6746
6	Capacitive Touch Display Module	Rs.6487
7	Accessories Display Module	Rs.401

Related Searches

Popular Searches

1. What is a display module?

A display module is defined as a highly interactive real-time embedded system that is tuned to interact efficiently with the environment.

2. What displays can you use with Arduino?

Arduino is compatible with many display types including 16x2 character LCDs (text-based), graphical LCDs (128x64 pixels), 7-segment displays (numeric), TFT color touchscreens (480x320), OLED displays (small, high-contrast), and dot matrix LED arrays (8x8). Choose based on project needs: character LCDs for simple text, TFT for graphics/colors, 7-segment for numeric data, OLED for compact designs.

3. What is an LCD display module?

An LCD display module is an electronic display module with numerous applications. As previously stated, LCD display modules are the most commonly used 16*2 type of display module in various devices and circuits. An LCD module generates an image by using liquid crystals. These liquid crystals are embedded in a display screen and illuminated by a backlight. The LCD display module itself is comprised of several layers, including polarising filters and electrodes. The backlight is critical in the LCD display module. The LCD display module cannot produce visible images without this backlight.

4. What is OLED display module?

An OLED is an Organic Light-Emitting Diode. OLED display Modules are thin, multi-layered organic films sandwiched between an anode and a cathode that comprise the self-emitting OLED Display. In contrast to LCD technology, OLED Display Modules do not require a backlight.

5. What is the difference between LED and OLED?

LED and LCD screens use a backlight to illuminate their pixels, whereas OLED pixels generate their own light. OLED pixels are known as self-emissive,' whereas LCD pixels are known as 'transmissive.' An OLED display's light can be controlled pixel by pixel.

6. What is TFT LCD?

TFT LCD (thin-film transistor liquid-crystal display) is a type of liquid-crystal display that improves image qualities such as addressability and contrast by utilising thin-film transistor technology. A TFT LCD is an active matrix LCD, as opposed to a passive matrix LCD or a few simple, direct-driven (directly connected to electronics outside the LCD) LCDs. Televisions, computer monitors, mobile phones, handheld devices, video game systems, personal digital assistants, navigation systems, projectors, and automobile dashboards all use TFT LCDs.

7. How does a 7-segment display work?

A 7-segment display contains seven LEDs (Light Emitting Diodes) arranged in a rectangular pattern, plus an eighth decimal point LED. Each segment illuminates individually or in combinations to form numbers (0-9) and some letters. When Arduino sends signals to activate specific segments, they light up to display the desired digit. By controlling which segments turn on/off, you create any number or character needed

8. Why it is called a 7-segment?

It's called a 7-segment display because it contains exactly seven individual LED segments arranged in a specific rectangular pattern that resembles the numeral ""8."" Each segment can illuminate independently. When the seven segments are activated in different combinations, they form digits 0–9 and some letters. The eighth LED, optional, serves as a decimal point, not a segment.

9. What is an E Ink screen?

E Ink displays are referred to as ""reflective displays."" An LCD's backlight, also known as an ""emissive display,"" directs light through the screen and into your eyes. An E Ink display does not use a backlight; instead, ambient light from the surroundings is reflected off the display's surface and back to your eyes.

10. Which display module is best for Arduino projects?

If you’re using Arduino and want something reliable, simple, and well-supported, a compact monochrome OLED like the 0.96″ 128×64 is hard to beat. It draws very little power, connects via I²C or SPI with just a handful of pins, and works great for projects that show text, small graphics, or sensor output. If you expect richer visuals (colour, icons, images) you might lean toward a larger TFT display, but for many Arduino projects the smaller OLED hits the sweet spot of ease, clarity, and cost.

11. Are these OLED displays compatible with Raspberry Pi?

Yes, many of these display modules work fine with Raspberry Pi too. Because they often use standard communication protocols (I²C or SPI) and accept 3.3 V or 5 V logic, you can connect them to the Pi’s GPIO pins and drive them from Python or other languages. So if you build a Raspberry Pi dashboard or an IoT smart device, you can use these displays just as well as with an Arduino.

12. What resolutions and sizes are available?

The world of display modules spans from tiny screens like 0.66″ with 64×48 pixels, through 0.96″ or 1.3″ OLEDs at 128×64 pixels, up to larger panels such as 2.4″ or 3.2″ TFTs with colour and maybe 240×320 or more pixels. For example, a 0.96″ OLED might measure 26×27 mm with 128×64 resolution and work at 3.3-5 V. The choice depends on how much visual “real-estate” your project needs — simple text can work on a small screen, while dashboards with graphs or icons may call for a larger panel.

13. Can these displays be used for DIY dashboards and smart devices?

Absolutely. These displays are ideal for DIY dashboards (sensor readouts, status displays, control panels) and smart devices (wearables, IoT modules, handheld controllers). Because they are compact, cost-effective, and supported by many libraries, you can integrate them into projects that show live data, graphics, user menus, alerts or animations. Whether you’re building a smart home controller, a weather station, or a robot interface, adding one of these displays instantly makes your device feel interactive and polished.
