Microbit vs Microbit V2

Microbit vs Microbit V2

Microbit vs Microbit V2





Characteristics

Microbit V1.5

Microbit V2

Processor

Nordic Semiconductor

nRF51822

Nordic Semiconductor

nRD52833

Flash Memory

256KB Flash

512kB Flash

RAM

16kB

128kB

Interface

NXP KL26Z

16kB RAM

NXP KL27Z

32kB RAM

Edge Connector

25 pins. 3 Dedicated GPIO, PWM, i2c, SPI, and ext. Power. 3 ring pins for connecting crocodile clips/banana plugs

25 pins. 4 Dedicated GPIO, PWM, i2c, SPI, and ext. Power. 3 ring pins for connecting crocodile clips/banana plugs

I2C

Shared i2c Bus

Dedicated i2c bus for peripherals

Wireless

2.4 GHz Microbit Radio

2.4 GHz Microbit Radio

BLE Bluetooth

Bluetooth 4.0

Bluetooth 5.0

Power

5V via Micro USB Port,

3V via edge connector or battery pack.

5V via Micro USB Port,

3V via edge connector or battery pack, LED power indicator, Power off(push and hold power button)

Current Available

90 mA

Available for accessories

200 mA

Available for accessories

Motion Sensor

ST LSM 303

ST LSM 303

Size

5cm x 4cm (w x h)

5cm x 4cm (w x h)

Reset Button

Rear Mounted Push Button

Rear Mounted Push Button

Microphone

No microphone

MEMs Microphone and LED indicator

Speaker

No Speaker

On-Board Speaker

Logo Touch

Not present

Touch-sensitive Logo Pin

Software

C++, MakeCode,Python,Scratch

C++, Make Code, Python, Scratch

Cost

Rs. 1700 /-

Rs.2300/-





Microbit

Microbit  V2 link

Additions on the Microbit V2

The Microbit V2 has come up with certain additions to it, that Microbit V1.5 lacked.

  1. The Microbit V2 has an additional  Microphone input and an LED indicator that shows the Microphone is on.
  2. As there is a Microphone Input there is also a Speaker that comes with the Microbit V2.
  3. The Microbit logo on the V2 is now touch-sensitive ie. it now acts as an additional input along with the two buttons ‘A’ and ‘B’ that were the only physical inputs in Microbit V1.5.
  4. With 3 GPIO pins already in Microbit V 1.5, the V2 has an additional GPIO making it 4 GPIO.
  5.  The Microbit V2 has an enhanced processor on board along with increased Flash and RAM capacity.
  6. The current availability for accessories is also increased from 90mA to 200mA.
  7. The Interface chip is more advanced and has more RAM capacity than the one used in Microbit V1.5

check out full BBC Microbit collection



Choosing a Microbit for your Application

After specifying the Differences and new additions to Microbit v2, it is fairly clear

  1. You should prefer the Microbit V2 if you need to have a microphone and speaker configuration in your project.
  2. If the Code that you are uploading is big and might only get bigger, go for the Microbit V2, as it has better interface capabilities.
  3. If you need additional input on the board in form of touch apart from the two buttons, you can choose the Microbit V2.
  4. As the cost difference is not significant when compared to the additional features that come up with the Microbit V2, there is no turning back from buying the V2.
