4-Channel 5V Relay Board

4-Channel 5V Relay Board

Rs. 136
Rs. 204 Rs. 136
Sale Sold out 33% off Best Price Guaranteed
You save Rs. 68 | Free Shipping on Orders Above ₹ 499/-
Incl. GST (No Hidden Charges)
Currently, people are actively viewing.

BEST COUPON FOR YOU

FLAT ₹ 100/- OFF RC100

When you shop for ₹ 2500 or more.Applicable on Checkout.

*Coupons are not applicable on Original Boards and Kits

Submit your Bulk Enquiry Here
  • One normally closed contact and one normally open contact.
  • Energization status indicator light, release status led is off; vice for the system power, JD-VCC for the relay power.
  • Default hair 5v relay, plug the jumper cap to.
  • Relay Maximum output: dc 30v/10a, ac 250v/10aRelay selection of quality loose music relays, spat.
  • A common terminal, a normally open, one normally closed terminal. optocoupler isolation, good anti-jamming.
Trust Badge 1 Trust Badge 2 Trust Badge 3

4-Channel 5V Relay Board

This 4 channel 5 V relay module is a low pull, high release relay module and features energization status indicator light, release status led is off. By default, this is a 5V relay module and uses jd-vcc for the relay power and is compliant with international safety standards, control and load areas isolation trenches. The 4 Channel Relay Module is a convenient board which can be used to control high voltage, high current load such as motor, solenoid valves, lamps and AC load. It is designed to interface with microcontroller such as Arduino, PIC and etc. The relays terminal (COM, NO and NC) is being brought out with screw terminal. It also comes with a LED to indicate the status of relay.

The 4 channel relay module can be used to control various various appliances and other types of equipment with large current. The maximum output of the relay module is AC250V 10A and DC5V 10A.

Applications:

  • Switching mains loads
  • Home automation
  • Battery backup
  • High current load switching

Also check 8 Channel 5V 10A Relay Module which is equipped with high-current relays, with each relay having normally open and normally closed contacts.

Also check our relay switch collection, with various relay switch products with different specifications and prices. The available relay switch categories include 5V Relays, 12V Relays, Solid State Relays, and more.

Package Includes:

  • 1 x 4 channel 5 V Relay

Specifications

Number of Channels  4
Operating Voltage  5V
MAx Output  AC250V 10A and DC5V 10A
Dimensions  5 x 3 x 1cms
Weight  5 grams

Shipping & Returns

  • All orders confirmed before 3 pm IST are shipped on the
    same day, barring rare pickup delays on holidays or disturbances
  • Delivery time in Metro cities is 1-3 days, Others it is
    3-7 days. It varies based on location, reliant on courier services
  • Return window: 7 days from receipt unless stated
    otherwise. No refunds/replacements after
  • Returns only for non-working/damaged products are accepted
  • Initiate return requests to our customer service team via Support ticket or contact us at +91-8123057137
  • Refunds are processed within 3-4 working days post inspection and approval.

For more details, please check our Shipping and Return Policy

View full details
Trust Badge 1 Trust Badge 2 Trust Badge 3

Found a better price?

Let us know!
We'll try to match the price for you

  • ⚡ Dispatched within 24 hours

  • 💰 Earn RC Coins on every purchase

  • 🚚 Free shipping on orders above Rs 500/-

  • 🛠️ Dedicated Technical Support Team

1 4

1. What is a 4 channel relay module?

  • The 4 Channel Relay Module is a convenient board that can control high voltage and high current loads such as motor, solenoid valves, lamps, and AC load. It is designed to interface with microcontrollers such as Arduino, PIC, etc.

2. How does 4 channel relay work?

  • The 4 channel Relays are the switches that open and close circuits electronically. Relays control one electrical circuit by opening and closing contacts in another circuit. When a relay contact is normally open (NO), there is an open contact when the relay is not energized. When a relay contact is Normally Closed (NC), there is a closed contact when the relay is not energized. In either case, applying electrical current to the contacts will change their state

3. What are the components present on a four-channel relay module?

  • The major components present on the 4-channel 5V relay board are terminal blocks, male headers, transistors, optocouplers, diodes, and LEDs.

4. How do you connect 4 Channel relay modules to Arduino?

  • NC: Normally closed 120-240V terminal
  • NO: Normally open 120-240V terminal
  • C: Common terminal
  • Ground: Connects to the ground pin on the Arduino 5V
  • Vcc: Connects the Arduino’s 5V pin
  • Signal: Carries the trigger signal from the Arduino that activates the relay

5. What are Normal Open and Normal Closed in a 4-channel 5V relay board?

  • The 4 channel relay module has two different types of electrical contacts inside normally open (NO) and normally closed (NC). The one you use will depend on whether you want the 5V signal to turn the switch on or turn the switch off. The 120-240V supply current enters the relay at the common (C) terminal in both configurations. To use the normally open contacts, use the NO terminal. To use the normally closed contacts, use the NC terminal.
