Build a Raspberry Pi 5 and OpenCV Based Face Recognition

Build a Raspberry Pi 5 and OpenCV Based Face Recognition - Cover image

Summary

After countless late nights tinkering with computer vision projects, I can confidently say that the intersection of affordable hardware and powerful AI libraries has never been more exciting.

When I first got my hands on the Raspberry Pi 5, I immediately knew I had to push its limits with a project that would truly showcase its enhanced capabilities.

The fascinating realm of computer vision has become remarkably accessible, transforming what once required expensive specialized hardware into achievable home projects that anyone can tackle on a weekend.Β

In this comprehensive walkthrough, we'll dive deep into creating your own face recognition system using the Raspberry Pi 5 and OpenCV.

Whether you're a hobbyist looking to enhance your home security setup, a student exploring computer vision concepts, or a maker wanting to add intelligent features to your projects, this guide will take you through every step of building a functional face recognition system from scratch. Β

Build a Raspberry Pi 5 and OpenCV Based Face Recognition - Cover image

What is OpenCV

After working with various computer vision libraries over the years, I keep coming back to OpenCV for one simple reason: it just works reliably across different platforms and use cases.

OpenCV (Open-Source Computer Vision Library) stands as one of the most powerful and versatile computer vision libraries available today, and I've personally witnessed its evolution from a research tool into the backbone of countless commercial applications.

What initially drew me to OpenCV was its incredible versatility - this remarkable toolkit provides developers with an extensive collection of algorithms and functions specifically designed for real-time computer vision applications.

Originally developed by Intel in 1999, OpenCV has evolved into a comprehensive platform that supports multiple programming languages and operating systems, and I've used it successfully on everything from high-end workstations to tiny embedded devices.

For face recognition applications, OpenCV provides several pre-trained models and algorithms, including Haar Cascade classifiers and more modern deep learning approaches.

These tools enable developers to detect faces in images and video streams with remarkable accuracy, making it an ideal foundation for building sophisticated recognition systems on affordable hardware platforms.

Components and Tools Required

Having built dozens of Raspberry Pi projects with camera over the years, I've learned the hard way which components are absolutely essential and which ones you can skimp on. Let me share the exact setup that has given me the most reliable results for Raspberry Pi 5 face recognition projects, along with some hard-earned wisdom about what works and what doesn't.

Essential Hardware:

After burning through several cheaper power supplies in previous projects, I cannot stress enough how crucial the official power adapter is for this raspberry pi based project. The Pi 5's increased power requirements mean that inadequate power will cause frustrating crashes during intensive opencv face recognition processing.

Optional Components:

  • Ribbon Cable Adapter (if using older camera modules with Pi 5)
  • Case for protection and better cable management
  • External Storage (USB drive for storing training images and models)

The active cooling solution isn't optional if you plan to run continuous face recognition - I learned this lesson during a 6-hour testing session that ended with thermal throttling bringing my frame rate to a crawl.

Set Up Your Raspberry Pi 5

Setting up the Raspberry Pi 5 for computer vision work taught me patience the first time around, but I've since streamlined the process to avoid the common pitfalls that can waste hours of your time. Getting your Raspberry Pi 5 ready for this opencv project begins with a fresh installation of the operating system, and I've found that taking the time to do this properly saves countless headaches later.

Initial Setup Process:

I always start by downloading the latest Raspberry Pi OS image using the official Raspberry Pi Imager tool - it's genuinely the most reliable method I've found. Flash your microSD card with Raspberry Pi OS and insert it into your Pi 5. Connect your monitor, keyboard, mouse, and power supply. During the first boot, you'll be guided through the initial configuration wizard where you'll set up your WiFi connection, enable SSH if needed, and update the system locale settings.

System Updates and Preparation:

The first thing I do after any fresh install is update the system - this step has saved me from mysterious compatibility issues more times than I can count. Open the terminal and update your package repositories:Β


sudo apt update sudo apt upgrade -y

Enable Camera Interface:

From my experience with multiple Raspberry Pi 5 project builds, forgetting to enable the camera interface is the most common oversight. Navigate to the Raspberry Pi Configuration tool through the main menu or use the command line:


sudo raspi-config

Select "Interface Options" and enable the camera interface. This step is crucial for your face detection with the Raspberry Pi 5 project to access the camera module properly. Always reboot after making these changes - I've seen too many projects fail because someone skipped this simple step.

Install OpenCV and Python Libraries

I remember spending an entire weekend compiling OpenCV from source on a Raspberry Pi 3. Fortunately, the installation process for how to install OpenCV on Raspberry Pi 5 has been streamlined significantly. The OpenCV library can now be installed using pre-compiled packages, and I've tested this method across multiple Pi 5 setups with consistent success.

Installing Core Dependencies:

Based on my testing with various OpenCV project configurations, this combination of packages provides the most stable foundation:

bash


sudo apt install python3-pip python3-numpy python3-opencv -y

This command installs the OpenCV library along with NumPy, which is essential for numerical operations in image processing. I've found that the pre-compiled OpenCV package for Raspberry Pi includes most common functionality needed for computer vision projects, eliminating the compilation headaches I used to face.

Additional Required Libraries:

After experimenting with different face recognition approaches, I've settled on this specific combination that delivers the best balance of accuracy and performance:

bash


pip3 install face-recognition imutils picamera2

The Python face recognition library provides high-level functions that dramatically simplify implementation compared to building everything from scratch with raw OpenCV. Trust me β€”I've tried both approaches, and unless you have very specific requirements, this library will save you weeks of development time.

Verification of Installation:

I always test installations immediately to catch problems early. Open a Python3 shell and verify everything works:

Python code


import cv2
import face_recognition
from picamera2 import Picamera2
print("OpenCV version:", cv2.__version__)

If all imports succeed without errors, you're ready to proceed. In my experience, installation issues are usually caught at this stage, making them much easier to troubleshoot.

Connect the Camera to Raspberry Pi 5

Having wrestled with camera connections across multiple Raspberry Pi generations, I can tell you that the Pi 5's updated connector initially caught me off guard. Proper camera connection is absolutely crucial for your Raspberry Pi 5 project success, and I've learned some tricks that can save you from the frustration I experienced during my first attempt.

Physical Connection:

The most important lesson I learned: always power down your Raspberry Pi 5 completely before connecting the camera. I once damaged a camera module by hot-plugging it, and that's a mistake you only make once. Locate the CSI (Camera Serial Interface) connector near the HDMI ports β€”it's smaller than previous Pi models, which initially confused me.

The connector has a plastic clip that lifts up to allow cable insertion. Insert the camera ribbon cable with the blue side facing away from the Ethernet port. I've found that ensuring the connection is perfectly aligned before closing the clip prevents the intermittent connection issues that plagued my early attempts.

Camera Module Compatibility:

After testing various camera modules, I can confidently recommend that the Raspberry Pi 5 face recognition system works best with the camera module V2. The autofocus capabilities are essential for clear face capture at various distances, and I've seen dramatic improvements in recognition accuracy compared to fixed-focus modules.

Testing Camera Functionality:

I always test the camera immediately after connection using this simple script:

python


from picamera2 import Picamera2
import cv2

picam2 = Picamera2()
picam2.configure(picam2.create_preview_configuration(main={"format": 'XRGB8888', "size": (640, 480)}))
picam2.start()

# Capture a test image
array = picam2.capture_array()
cv2.imshow("Camera Test", array)
cv2.waitKey(0)
cv2.destroyAllWindows()

This test has saved me hours of debugging later in the development process by confirming the camera works properly with OpenCV right from the start.

Collect and Save Face Images for Training

Through building multiple OpenCV face recognition systems, I've learned that the quality of your training data directly determines your system's success. This phase initially frustrated me because I underestimated its importance, but after seeing the dramatic difference that proper training data makes, I now consider it the most critical step in the entire process.

Creating the Training Dataset:

I always start with a well-organized directory structureβ€”it prevents confusion later when you're managing multiple people's data:

Creating the Training Dataset:

I always start with a well-organized directory structureβ€”it prevents confusion later when you're managing multiple people's data:

bash


mkdir -p ~/face_recognition/dataset
mkdir -p ~/face_recognition/models

Image Capture Script:

Now, we will create a Python script named

 β€œcapture_training_images.py”,

which will help us collect the images and process them in a systematic way.

After experimenting with different capture methods, I developed this systematic approach that consistently produces high-quality training datasets:

python


from picamera2 import Picamera2
import cv2
import os
import time

def capture_training_images(person_name, num_images=30):
    """Capture training images for a specific person"""

    # Create person directory
    person_dir = f"dataset/{person_name}"
    os.makedirs(person_dir, exist_ok=True)

    # Initialize camera
    picam2 = Picamera2()
    picam2.configure(picam2.create_preview_configuration(main={"format": 'XRGB8888', "size": (640, 480)}))
    picam2.start()

    print(f"Capturing {num_images} images for {person_name}")
    print("Press SPACE to capture image, ESC to exit")

    count = 0
    while count < num_images:
        # Capture frame
        frame = picam2.capture_array()

        # Display frame
        cv2.putText(frame, f"Images captured: {count}/{num_images}",
                   (10, 30), cv2.FONT_HERSHEY_SIMPLEX, 1, (0, 255, 0), 2)
        cv2.imshow("Capture Training Images", frame)

        key = cv2.waitKey(1) & 0xFF

        if key == ord(' '):  # Space key to capture
            filename = f"{person_dir}/{person_name}_{count+1}.jpg"
            cv2.imwrite(filename, frame)
            print(f"Saved: {filename}")
            count += 1
            time.sleep(0.5)  # Brief pause between captures

        elif key == 27:  # ESC key to exit
            break

    picam2.stop()
    cv2.destroyAllWindows()
    print(f"Captured {count} images for {person_name}")

Based on my testing with dozens of recognition systems, capturing 25-30 high-quality images per person provides the optimal balance between training time and accuracy.

Running the Image-Capture Script

Next, we have to run this script so that it collects the images, which we will use it to train a model in the next step. Just follow the steps below:

1. Open a terminal on your Raspberry Pi 5

Navigate to the folder where you saved the script:

bash


cd ~/face_recognition

2. Start the script.

bash


python3 capture_training_images.py
  • When prompted, type the person’s name exactly as you want it stored (e.g., Alice).
  • Press Enter.

3. Position yourself (or the target person) in front of the camera.

Stand or sit so the face is clearly visible in the preview window. Good lighting and head-and-shoulders framing improve results.

4. Capture images.Β

  • Press the Spacebar to save a frame.
  • The counter on-screen shows how many of the requested 30 images have been stored.Β
  • Move slightly between shotsβ€”turn your head left/right, vary expressions, step closer or fartherβ€”to give the model useful variety.
  • If you need to abort, press Esc.

5. Finish the session.

After 30 images (or whatever number you set), the script closes automatically, saves all photos in ~/face_recognition/dataset/person_name/, and returns to the prompt.

6. Repeat for each person.

Run the script again with a new name to collect another set of training images.

That’s it. We have captured the images, and they are now ready for training.

Training the Model

Now that we’ve collected the images, let’s now train a model. We will write a new script named β€œtrain_model.py”, that will train a model using the images that we collected earlier.

After writing and debugging countless opencv face recognition implementations, I've refined this code to handle the edge cases and performance issues that typically cause problems for beginners. Let me walk you through the script that trains a model which hopefully creates a reliable face recognition system.

Face Encoding Script

python


import face_recognition
import os
import pickle
import cv2
from imutils import paths

def train_face_recognition_model():
    """Train the face recognition model using collected images"""

    print("[INFO] Quantifying faces...")

    # Get paths to all training images
    image_paths = list(paths.list_images("dataset"))

    # Initialize lists for encodings and names
    known_encodings = []
    known_names = []

    # Process each image
    for (i, image_path) in enumerate(image_paths):
        print(f"[INFO] Processing image {i+1}/{len(image_paths)}")

        # Extract person name from path
        name = image_path.split(os.path.sep)[-2]

        # Load image and convert BGR to RGB
        image = cv2.imread(image_path)
        rgb = cv2.cvtColor(image, cv2.COLOR_BGR2RGB)

        # Detect face locations
        boxes = face_recognition.face_locations(rgb, model="hog")

        # Compute facial encodings
        encodings = face_recognition.face_encodings(rgb, boxes)

        # Add each encoding + name to our lists
        for encoding in encodings:
            known_encodings.append(encoding)
            known_names.append(name)

    # Save encodings to disk
    print("[INFO] Serializing encodings...")
    data = {"encodings": known_encodings, "names": known_names}
    with open("models/encodings.pickle", "wb") as f:
        pickle.dump(data, f)

    print("[INFO] Training complete!")

if __name__ == "__main__":
    train_face_recognition_model()

Run this script, using the command below, and you will have a model trained on the images that you captured earlier.

bash


cd ~/face_recognition
python3 train_model.py

Run and Test Your Face Recognition System

Now it’s time to test how good the model is and whether it’s able to correctly recognize your face.

For that, we will write another script, named

β€œface_recognition_live.py”,

which will do the following things:

Β

  • Startup Phase: Automatically loads your saved face encodings from encodings.pickle and initializes the Raspberry Pi Camera using the modern Picamera2 interface
  • Continuous Frame Processing: Captures live video frames, converts them from BGR to RGB color format, and detects all face locations within each frame using OpenCV's detection algorithms
  • Real-Time Face Identification: Generates a 128-dimensional embedding for every detected face and compares it against your stored database using Euclidean distance calculations to determine the closest match
  • Visual Feedback System: Draws green bounding boxes around detected faces and displays either the recognized person's name or "Unknown" for unidentified faces directly on the live video feed
  • User Control Interface: Provides a clean exit mechanism - simply press 'q' to stop the camera stream and close all windows gracefully

python


import face_recognition
import pickle
import cv2
from picamera2 import Picamera2
import numpy as np

def load_known_faces():
    """Load the trained face encodings"""
    print("[INFO] Loading encodings...")
    with open("models/encodings.pickle", "rb") as f:
        data = pickle.load(f)
    return data

def recognize_faces_live():
    """Perform live face recognition"""

    # Load known face encodings
    data = load_known_faces()

    # Initialize camera
    picam2 = Picamera2()
    picam2.configure(picam2.create_preview_configuration(main={"format": 'XRGB8888', "size": (640, 480)}))
    picam2.start()

    print("[INFO] Starting face recognition... Press 'q' to quit")

    while True:
        # Capture frame from camera
        frame = picam2.capture_array()

        # Convert BGR to RGB
        rgb = cv2.cvtColor(frame, cv2.COLOR_BGR2RGB)

        # Detect faces in current frame
        boxes = face_recognition.face_locations(rgb)
        encodings = face_recognition.face_encodings(rgb, boxes)

        # Initialize list of names for detected faces
        names = []

        # Process each face encoding
        for encoding in encodings:
            # Compare face encoding with known faces
            matches = face_recognition.compare_faces(data["encodings"], encoding)
            name = "Unknown"

            # Calculate face distances
            face_distances = face_recognition.face_distance(data["encodings"], encoding)
            best_match_index = np.argmin(face_distances)

            # Check if we have a match
            if matches[best_match_index]:
                name = data["names"][best_match_index]

            names.append(name)

        # Draw rectangles and labels on faces
        for ((top, right, bottom, left), name) in zip(boxes, names):
            # Draw rectangle around face
            cv2.rectangle(frame, (left, top), (right, bottom), (0, 255, 0), 2)

            # Draw label below face
            y = top - 15 if top - 15 > 15 else top + 15
            cv2.putText(frame, name, (left, y), cv2.FONT_HERSHEY_SIMPLEX, 0.75, (0, 255, 0), 2)

        # Display frame
        cv2.imshow("Face Recognition", frame)

        # Break on 'q' key press
        if cv2.waitKey(1) & 0xFF == ord('q'):
            break

    # Cleanup
    picam2.stop()
    cv2.destroyAllWindows()

if __name__ == "__main__":
    recognize_faces_live()

I've found this implementation strikes the perfect balance between accuracy and real-time performance on Raspberry Pi 5 hardware.

Live Recognition Testing:

Now it’s time to run the program and see if it works. Type the following code in the terminal:

bash


python3 face_recognition_live.py

I remember the satisfaction of seeing my name appear above the green rectangle for the first time - it validated weeks of development work. Test different angles, lighting conditions, and distances to evaluate system robustness.

Performance Optimization (optional step):

Through extensive testing, I've learned to monitor system resources during operation:

bash


# Check CPU and memory usage
htop

# Monitor temperature to prevent throttling
vcgencmd measure_temp

The Raspberry Pi 5 improved processing power handles real-time opencv face detection remarkably well, but monitoring ensures optimal performance during extended operation sessions.

Β

Β

Conclusion

Looking back on this comprehensive journey through building a Raspberry Pi 5 face recognition system, I'm continually amazed by how accessible advanced computer vision technology has become.

When I started working with computer vision years ago, this level of functionality required expensive workstations and months of development time - now it fits comfortably on a desk and can be built on a weekend.Β

The skills and knowledge gained from this project extend far beyond face recognition, providing a solid foundation for exploring other computer vision challenges and machine learning applications on embedded systems.

Components and Supplies

You may also like to read

Frequently Asked Questions

Back to blog

Leave a comment

Please note, comments need to be approved before they are published.

Components and Supplies

You may also like to read
