2 Channel Logic Level Converter (I2C, UART, 5V-3.3V)
2 Channel Logic Level Converter (I2C, UART, 5V-3.3V)
Regular price
Rs. 19
Regular price
Rs. 24
Sale price
Rs. 19
Unit price
per
Incl. GST (No Hidden Charges)
Currently, people are actively viewing.
Couldn't load pickup availability
BEST COUPON FOR YOU
FLAT ₹ 100/- OFF
RC100
When you shop for ₹ 2500 or more.Applicable on Checkout.
*Coupons are not applicable on Original Boards and Kits
- This level converter also works with 2.8V and 1.8V devices
- A bi-directional logic level converter is a small device that safely steps down 5V signals to 3.3V AND steps up 3.3V to 5V at the same time
- Two inputs and two outputs are provided for each side.
- It can bidirectionally transfer with 2 channels between high logic voltage and low logic voltage
- This logic level converter is compatible with Arduino, Raspberry Pi and STM32.
2 Channel Logic Level Converter (I2C, UART, 5V-3.3V)
The 2 Channel Logic Level Converter is a small device that safely steps down 5V signals to 3.3V and steps up 3.3V to 5V. This level converter also works with 2.8V and 1.8V devices. Each level converter has the capability of converting 4 pins on the high side to 4 pins on the low side. Two inputs and two outputs are provided for each side. This logic level converter is compatible with Arduino, Raspberry Pi and STM32.
Each level converter has the capability of converting 4 pins on the high side to 4 pins on the low side with two inputs and two outputs provided for each side. The level converter is very easy to use. The board needs to be powered from the two voltages sources (high voltage and low voltage) that your system is using. High voltage (5V for example) to the HV' pin, low voltage (3.3V for example) to LV', and ground from the system to the GND' pin.
Application:
- TTL Logic Level Converter
- Bidirectional Logic Level Conversion
Package Includes:
- 1 x 2 Channel Logic Level Converter
Specifications:
| High Voltage | 5V |
| Low Voltage | 3.3V |
| No. of Channels | 2 |
| Dimensions | 15 x 15 x 2mm |
| Weight | 2g |
