Holybro Micro M9N GPS With Case
Let us know!
We'll try to match the price for you
Couldn't load pickup availability
The Holybro Micro M9N GPS With Case is a compact, high-performance M9N GPS with case module designed to deliver precise positioning and reliable navigation for advanced drone and UAV applications. Featuring multi-constellation GNSS support, this GPS unit tracks multiple satellite systems simultaneously to ensure fast satellite acquisition, improved accuracy, and strong signal reliability. The included protective case not only enhances durability but also simplifies mounting and installation on a variety of drone frames and robotic platforms.
Equipped with an IST8310 compass and a high-performance antenna, this GPS module provides accurate heading information and robust signal reception, enhancing overall flight stability and control. Whether you’re conducting waypoint missions, autonomous navigation, or complex aerial maneuvers, the Holybro Micro M9N GPS With Case delivers dependable performance in both indoor and outdoor environments. Its lightweight design and advanced features make it an excellent choice for hobbyist builders and professional UAV developers alike.
| Item Type | GPS |
| Concurrent GNSS | Up to 4 GNSS – BeiDou, Galileo, GLONASS, GPS, QZSS |
| Frequency Band | GPS L1, Galileo E1, GLONASS L1, BeiDou B1, SBAS L1, QZSS L1 |
| Navigation Update Rate | Up to 25 Hz (4 concurrent GNSS) |
| Baud Rate | 115200 |
| Input Voltage | 4.7 – 5.2 V |
| Current Consumption | < 200 mA @ 5 V |
| Operating Temperature | -40 to 80 °C |
| Overall Dimensions |
32 × 26 × 9 mm (without case) 34 × 28 × 11 mm (with case) |
| Weight |
14 g (without case) 16 g (with case) |
