Dual-channel isolated gate driver breakout for MOSFETs, IGBTs, and SiC devices.
Peak source current: 4A; Peak sink current: 6A.
3kVRMS isolation between input and output for safe high-voltage operation.
Programmable dead-time control to reduce switching losses and prevent shoot-through.
Built-in undervoltage lockout (UVLO) and disable function for enhanced protection.
Ideal for motor drives, power converters, and industrial automation applications.

BEST COUPON

RC100

COPY CODE

When you shop for ₹ 2,500 required. Applicable at Checkout.
*Coupons are not applicable on Original Boards and Kits

Why Buy From Robocraze

Free shipping on Orders Above Rs 999/-

Technical Support & Easy Returns

Same Day Shipping

Earn RC Coins on Every Purchase

Cash on Delivery Available

Bulk Order?

For Best Price Contact on WhatsApp for bulk discounts!
Or Fill the Form Below

Submit your Bulk Enquiry Here

First Name *

Last Name *

Email *

Phone *

Company

Materials List

File(s) size limit is 20MB.

Enter the Captcha *

Captcha challenge – enter the characters shown in the image

Reload Captcha

7Semi UCC21330 Dual-channel Isolated Gate Driver Breakout Board

~~Rs. 465~~ Rs. 370

Quantity:

7Semi UCC21330 Dual-channel Isolated Gate Driver Breakout Board

~~Rs. 465~~ Rs. 370

Description
Specifications
Shipping & Return

Description

7Semi UCC21330 Dual-channel Isolated Gate Driver Breakout Board

The 7Semi UCC21330 Dual-Channel Isolated Gate Driver Breakout Board is designed to efficiently drive power transistors like MOSFETs, IGBTs, and SiC devices with a peak source current of 4A and a peak sink current of 6A.

Its 3kVRMS isolation barrier ensures safe and reliable operation in high-voltage environments, while programmable dead-time control allows precise timing adjustments to minimize switching losses and prevent shoot-through.

Integrated protection features, including undervoltage lockout (UVLO) and a disable function, safeguard your system and enable immediate shutdown when needed.

This compact breakout board is perfect for applications such as motor drives, power converters, and industrial automation systems requiring precise and reliable gate driving.

Features:

Supports dual low-side, dual high-side, and half-bridge configurations for a wide range of power applications.
High Current Capacity: 4A peak source and 6A peak sink output provide robust transistor control.
Enhanced Protection: All power supplies include UVLO protection and a configurable dead time for safe operation.
Precision timing is achieved with a 33ns mean propagation latency and a maximum pulse-width distortion of 5ns.
Robust CMTI operation: Common-mode transient immunity of more than 125V/ns enables dependable operation in high-noise settings.
Fast Disable Logic: The built-in disable feature allows you to shut down both outputs at the same time.

Specifications

Package Includes:

1 x 7Semi UCC21330 Dual-channel Isolated Gate Driver Breakout Board

Specifications:

Specification	Details
Compatible Devices	MOSFETs, IGBTs, SiC devices
Peak Source Current	4A
Peak Sink Current	6A
Isolation Voltage	3kVRMS
Dead-Time Control	Programmable
