5A ACS712 Current Sensor

5A ACS712 Current Sensor

Regular price Rs. 85
Regular price Rs. 114 Sale price Rs. 85
Sale Sold out 25% off Best Price Guaranteed
You save Rs. 29
Incl. GST (No Hidden Charges)
Currently, people are actively checking out this product.
Submit your Bulk Enquiry Here

Contact form

  • Low-noise analog signal path.
  • 5 µs output rise time in response to step input current.
  • Small footprint, low-profile SOIC8 package.
  • 2.1 kV RMS minimum isolation voltage from pins 1-4 to pins 5-8.
  • 5.0 V, single-supply operation.
  • 185 mV/A output sensitivity.
  • Output voltage proportional to AC or DC currents.
  • Factory-trimmed for accuracy.
  • Extremely stable output offset voltage.
  • Nearly zero magnetic hysteresis.
  • The ratio metric output from the supply voltage.

5A ACS712 Current Sensor

The 5A ACS712 range Current Sensor Module consists of a precise, low-offset, linear Hall circuit with a copper conduction path located near the surface of the die. Applied current flowing through this copper conduction path generates a magnetic field in which the Hall IC converts into a proportional voltage.

Sensing and controlling current flow is a fundamental requirement in a wide variety of applications including, over-current protection circuits, battery chargers, switching mode power supplies, digital watt meters, programmable current sources, etc.

Connection Diagram:

Interfacing a current sensor with Arduino uno
Current Sensor Connection With Arduino

The curve of relation between the DC input voltage and measuring current:

Fig: Output Voltage vs. Sensed Voltage
read our blog explaining  Interfacing acs712 current sensor with Arduino, which provides information about the ACS712 current sensor, discussing its features, working principle, hardware requirements, and applications.


Package Includes:

  • 1 x 5A ACS712 Current Sensor

Specifications

Output sensitivity 185 mV/A
Single-supply operation 5.0V
Dimensions  3 x 2 x 1cms
Weight  5 grams
