RGB LED (Common Anode ) (Pack of 10)

RGB LED (Common Anode ) (Pack of 10)

Rs. 29
Rs. 46 Rs. 29
Sale Sold out 37% off
Incl. GST (No Hidden Charges)
Submit your Bulk Enquiry Here
Currently, 16 people are actively viewing.
Trust Badge 1

Free shipping on Orders Above Rs 499/-

Fast Delivery

Trust Badge 2

Technical Support & Easy Returns

Trust Badge 3

Earn RC Coins on Every Purchase

Rewards

Trust Badge 4

Cash on Delivery Available

Cash Delivery

COUPON

RC100 FLAT ₹ 100/- OFF

When you shop for ₹ 2500 or more.Applicable on Checkout.

*Coupons are not applicable on Original Boards and Kits

  • These are RGB LED (COMMON ANODE )
  • These RGB LED are convenient for DIY and repair equipment and electrical appliances
  • These are perfect use for home, office and industry electrical equipment and electrical appliances.
  •  RGB Common Anode LED make some beautiful colours with this 5mm tri-colour LED with separate red, green and blue LED chips inside.
  • They make a nice indicator and are fun to colour-swirl.
  • Red = 2V forward voltage; Green = 3.2V forward voltage; Blue = 3.2V forward voltage

RGB LED (Common Anode ) (Pack of 10)

RGB LED (Common Anode) makes some beautiful colors, this 10mm tri-color LED with separate red, green and blue LED chips inside! They make a nice indicator, and are fun to color-swirl. We like RGB LEDs because they color mix inside instead of appearing as 3 distinct LEDs.

These RGB LEDs are Common Anode type which means you connect one pin to 5V and then tie the other three legs to the ground through a resistor. Most of the people use CA( common anode) more than CC(common cathode) because multi-LED driver chips are often designed exclusively for Common Anode and can’t be used with Common-Cathode. These RGB LEDs have four pins: one for each color and a common anode. Use this one LED for three status indicators or pulse width modulation all three and get mixed colours! If you want to use these RGB LEDs with your Arduino project, then you will need few components like resistors , jumper wires and breadboard

Package Includes:

  • 10 x RGB LED (Common Anode)

Specifications

LED size 5mm
Red 2V forward voltage
Green 3.2V forward voltage
Blue 3.2V forward voltage
Dimensions  5 x 4 x 3cms
Weight  15 grams
  • All orders confirmed before 3 pm IST are shipped on the
    same day, barring rare pickup delays on holidays or disturbances
  • Delivery time in Metro cities is 1-3 days, Others it is
    3-7 days. It varies based on location, reliant on courier services
  • Return window: 7 days from receipt unless stated
    otherwise. No refunds/replacements after
  • Returns only for non-working/damaged products are accepted
  • Initiate return requests to our customer service team via Support ticket or contact us at +91-8123057137
  • Refunds are processed within 3-4 working days post inspection and approval.

For more details, please check our Shipping and Return Policy

View full details

People Also Buy

-37%
RGB LED (Common Cathode) (Pack of 10)-Robocraze

RGB LED (Common Cathode - Clear) (Pack of 10)

Rs. 29
Rs. 46 Rs. 29
Incl. GST (No Hidden Charges)
Sale
-48%
WS2812 8 Bit RGB LED (round)-Robocraze

WS2812 8 Bit RGB LED (round)

Rs. 44
Rs. 84 Rs. 44
Incl. GST (No Hidden Charges)
Sold out
-46%
WS2812 16 Bit RGB LED (round)-Robocraze

WS2812 16 Bit RGB LED (round)

Rs. 81
Rs. 149 Rs. 81
Incl. GST (No Hidden Charges)
Sold out

Found a better price?

Let us know!
We'll try to match the price for you

  • ⚡ Dispatched within 24 hours

  • 💰 Earn RC Coins on every purchase

  • 🚚 Free shipping on orders above Rs 500/-

  • 🛠️ Dedicated Technical Support Team

NaN -Infinity

1. Is this RGB LED common anode or cathode?

  • This RGB LED is a common anode. If the LED lights up with the red tip on the longest lead and the black on one of the other leads – you have a common anode RGB LED. If the LED lights up with the black tip on the longest lead and the red tip on one of the other leads – you have a common cathode RGB LED.

2. How do you wire a common anode RGB LED?

  • The connections are pretty simple. We connect the power pin (pin 2) of the RGB LED to +3V of power. This gives +3V of power to each of the anodes of the 3 LEDs. We then connect toggle switches to each of the other pins, which are the cathodes of each of the 3 LEDs.

3. What is the difference between common anode LED and common cathode LED?

  • Common Anode displays have all the LED Anodes connected together and need a display driver with outputs that become low to turn each segment on. Common Cathode displays have all the LED cathodes connected together and need a driver with outputs that become high to turn each segment on.

4. How does common anode work?

  • Common anode means that the anode (positive) side of all of the LEDs are electrically connected at one pin, and each LED cathode has its own pin. So turning on any particular segment will involve running a current from this common anode (positive) pin to the particular cathode (negative) pin for the desired segment.

5. How do you tell if RGB LED is common anode or cathode?

  • If you set your multimeter to continuity mode. You have a common anode RGB LED if the LED lights up with the red tip on the longest lead and the black tip on one of the other leads. You have a common cathode RGB LED if the LED lights up with the black tip on the longest lead and the red tip on one of the other leads.

6. How do you control common anode RGB LED?

  • The anode of the internal LEDs in a common anode RGB LED is all connected to the external anode lead. To control each colour, we will connect the anode lead to the positive terminal of the power supply and apply a LOW signal or ground to the red, green, and blue leads.
