Mornsun LI30-20B15PR2 AC/DC 30W DIN-Rail Power Supply
Mornsun LI30-20B15PR2 AC/DC 30W DIN-Rail Power Supply
s

Mornsun FREE SHIPPING BEST PRICE GUARANTEED

Mornsun LI30-20B15PR2 AC/DC 30W DIN-Rail Power Supply - Buy Online in India

Mornsun LI30-20B15PR2 AC/DC 30W DIN-Rail Power Supply

Rs. 1,715
Rs. 2,343
Rs. 1,715
Save Rs. 628
Incl. GST (No Hidden Charges) Found a better price?
Please hurry! Only 0 left in stock
SKU: DTIFPS0244
  • Universal 85-264VAC or 120-370VDC input voltage
  • Accepts AC or DC input (dual-use of same terminal)
  • Operating ambient temperature range -40℃ to +70℃
  • High I/O isolation voltage up to 4000VAC
  • Industrial-grade design
  • OVC III (EN61558-1 standards)
  • Low standby power consumption, high efficiency
  • Low ripple & noise
  • Output short circuit, over-current, over-voltage protection
  • Withstand 300VAC surge input for 5s
  • DIN rail TS35X7.5/ TS35X15 mountable

This product is not available for store pickup. Apologies for the inconvenience caused

BEST COUPON
RC100
COPY CODE
When you shop for ₹ 2,500 required. Applicable at Checkout.
*Coupons are not applicable on Original Boards and Kits

Free shipping on Orders Above Rs 499/-

Technical Support & Easy Returns

Same Day Shipping

Earn RC Coins on Every Purchase

Cash on Delivery Available

Robocraze Academy Limited Time Offer

Bulk Order?

For Best Price Contact on WhatsApp for bulk discounts!
Or Fill the Form Below

Submit your Bulk Enquiry Here
Enter the Captcha
Reload
Robocraze Academy Limited Time Offer
Mornsun LI30-20B15PR2 AC/DC 30W DIN-Rail Power Supply
Mornsun LI30-20B15PR2 AC/DC 30W DIN-Rail Power Supply
Rs. 2,343 Rs. 1,715
Mornsun LI30-20B15PR2 AC/DC 30W DIN-Rail Power Supply

Mornsun LI30-20B15PR2 AC/DC 30W DIN-Rail Power Supply

Rs. 2,343 Rs. 1,715
Description

Mornsun LI30-20B15PR2 AC/DC 30W DIN-Rail Power Supply

The LI30-20B15PR2 is a cost-effective, energy-efficient AC-DC converter from Mornsun. It is compliant with international EMC standards and safety approved to IEC/EN61000-4, CISPR32, EN55032, UL62368, IEC62368, and EN62368. It is also light weight and has an extremely compact design, making it ideal for space-saving applications. The LI30-20B15PR2 is ideal for a variety of applications, including industrial control equipment, machinery, and harsh environments.

check out : Mornsun LI30-20B12PR2 AC/DC 30W DIN-Rail Power Supply

Note:

  • Unless otherwise specified, parameters in this datasheet were measured under the conditions of Ta=25?, humidity<75%RH with nominal input voltage and rated output load
  • The room temperature derating of 5?/1000m is needed for operating altitude greater than 2000m
  • All index testing methods in this datasheet are based on our company's corporate standards
  • In order to improve the efficiency at high input voltage, there will be audible noise generated, but it does not affect product performance and reliability
  • The out case needs to be connected to the earth ( )of system when the terminal equipment in operating
  • The output voltage can be adjusted by the ADJ, clockwise to increase
  • Our products shall be classified according to ISO14001 and related environmental laws and regulations and shall be handled by qualified units
  • The power supply is considered a component which will be installed into the final equipment. All EMC tests should be confirmed with the final equipment

check out : Mornsun LI30-20B05PR2 AC/DC 30W DIN-Rail Power Supply

Specifications

Package Includes:

1 x  Mornsun LI30-20B15PR2 AC/DC 30W DIN-Rail Power Supply

Specifications:

Type DIN Rail Single Output
Output Power 30W
Series LI30-20B
Part Number LI30-20B15PR2
Mount DIN-Rail
IP Level  Non-Waterproof
Output Voltage 15V
Output Current 2A
