Mornsun LIF480-10B24R2 AC/DC 480W DIN-Rail Power Supply
Mornsun LIF480-10B24R2 AC/DC 480W DIN-Rail Power Supply
Out of stock
Couldn't load pickup availability
BEST COUPON FOR YOU
When you shop for ₹ 20000 or more.Applicable on Checkout.
*Coupons are not applicable on Original Boards and Kits
- Universal 85-264VAC or 120-370VDC input voltage
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -40℃ to +70℃
- Efficiency up to 94.5%
- High I/O isolation test voltage up to 3000VAC
- DC OK function
- Active PFC, PF > 0.99
- Low ripple & noise
- Output short circuit, over-current, over-voltage, over-temperature protection, input undervoltage protection
- DIN rail TS-35/7.5 or 15 mountable
- Ultra slim design with 48mm width
- Withstand 305VAC input voltage 5S
- Safety according to IEC/UL62368, EN61558
This product is not available for store pickup. Apologies for the inconvenience caused
Mornsun LIF480-10B24R2 AC/DC 480W DIN-Rail Power Supply
The LIF480-10B24R2 is a 480W AC/DC power supply from Mornsun. It has a universal input voltage of 85-264VAC or 120-370VDC, and an output voltage of 24V. The power supply is also equipped with a power factor correction (PFC) function, which helps to improve the efficiency of the power supply and reduce the amount of power that is wasted. The LIF480-10B24R2 is a compact and reliable power supply that is ideal for a variety of applications, including industrial automation, networking, and telecommunications.
Features:
- Universal input voltage of 85-264VAC or 120-370VDC
- Output voltage of 24V
- Power factor correction (PFC) function
- Compact and reliable design
- DIN rail mounting
Note:
- Unless otherwise specified, parameters in this datasheet were measured under the conditions of Ta=25℃, humidity<75%RH with nominal input voltage and rated output load
- The room temperature derating of 5℃/1000m is needed for operating altitude greater than 2000m
- All index testing methods in this datasheet are based on our company's corporate standards
- In order to improve the efficiency at high input voltage, there will be audible noise generated, but it does not affect product performance and reliability
- The out case needs to be connected to the earth ( )of system when the terminal equipment in operating
- The output voltage can be adjusted by the ADJ, clockwise to increase
- Our products shall be classified according to ISO14001 and related environmental laws and regulations and shall be handled by qualified units
- The power supply is considered a component which will be installed into the final equipment. All EMC tests should be confirmed with the final equipment
Package Includes:
1 x Mornsun LIF480-10B24R2 AC/DC 480W DIN-Rail Power Supply
Specifications:
| Specification | Value |
|---|---|
| Power | 480W |
| Input voltage | 85-264VAC or 120-370VDC |
| Output voltage | 24V |
| Output current | 20A |
| Isolation voltage | 3000VAC |
| Dimensions | 220 x 100 x 45mm |
| Weight | 1.5kg |
