Mornsun LI30-20B48PR2 AC/DC 30W DIN-Rail Power Supply
Mornsun LI30-20B48PR2 AC/DC 30W DIN-Rail Power Supply
Out of stock
Regular price
Rs. 1,715
Regular price
Rs. 2,343
Sale price
Rs. 1,715
Unit price
per
Incl. GST (No Hidden Charges)
Currently, people are actively viewing.
Couldn't load pickup availability
BEST COUPON FOR YOU
FLAT ₹ 100/- OFF
RC100
When you shop for ₹ 2500 or more.Applicable on Checkout.
*Coupons are not applicable on Original Boards and Kits
- Universal input voltage of 85-264VAC or 120-370VDC
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range of -40℃ to +70℃
- High I/O isolation voltage of up to 4000VAC
- Industrial-grade design
- OVC III (EN61558-1 standards)
- Low standby power consumption, high efficiency
- Low ripple & noise
- Output short circuit, over-current, over-voltage protection
- Withstand 300VAC surge input for 5s
- DIN rail TS35X7.5/ TS35X15 mountable
This product is not available for store pickup. Apologies for the inconvenience caused
Mornsun LI30-20B48PR2 AC/DC 30W DIN-Rail Power Supply
The LI30-20B48PR2 is a cost-effective and energy-efficient AC/DC power supply with 48VDC output. It has an extremely compact design that saves space on your DIN-Rail and is ideal for applications like industrial control and building automation.
Features:
- Compact design
- Energy-efficient
- Standard DIN-Rail mounting
- 48VDC output
- Wide input voltage range (85-264VAC or 120-370VDC)
- High current output (0.75A)
- High isolation voltage (4000VAC)
- Overvoltage, undervoltage, overcurrent, and overload protection
Note:
- Unless otherwise specified, parameters in this datasheet were measured under the conditions of Ta=25℃, humidity<75%RH with nominal input voltage and rated output load
- The room temperature derating of 5℃/1000m is needed for operating altitude greater than 2000m
- All index testing methods in this datasheet are based on our company's corporate standards
- In order to improve the efficiency at high input voltage, there will be audible noise generated, but it does not affect product performance and reliability
- The out case needs to be connected to the earth ( )of system when the terminal equipment in operating
- The output voltage can be adjusted by the ADJ, clockwise to increase
- Our products shall be classified according to ISO14001 and related environmental laws and regulations and shall be handled by qualified units
- The power supply is considered a component which will be installed into the final equipment. All EMC tests should be confirmed with the final equipment
Package Includes:
1 x Mornsun LI30-20B48PR2 AC/DC 30W DIN-Rail Power Supply
Specifications
| Power | 36W |
| Input voltage | 85-264VAC or 120-370VDC |
| Output voltage | 48VDC |
| Output current | 0.75A |
| Isolation voltage | 4000VAC |
| Dimensions | 220mm x 90mm x 60mm |
| Weight | 0.8kg |
