10.1inch HDMI Capacitive Touch Screen LCD (E) 1024×600 Supports Raspberry Pi

10.1inch HDMI Capacitive Touch Screen LCD (E) 1024×600 Supports Raspberry Pi

The Waveshare 10.1-inch HDMI Capacitive Touch Screen is a high-quality display designed for versatile applications, including Raspberry Pi, Jetson Nano, Windows PCs, and gaming consoles.

Featuring a 1024×600 resolution, this HDMI Capacitive Touch Display for Raspberry Pi offers crystal-clear visuals with responsive capacitive touch functionality. The screen leverages advanced capacitive touch technology, which uses the human body’s electrical induction to accurately register touch inputs, ensuring smooth and precise control.

Built with a four-layer composite glass screen, the inner layers are coated with ITO conductive material, which forms a sensitive circuit when touched by a conductive object like a finger. This results in a reliable, high-performance user interaction, much like the touch experience found in modern smartphones.

The Waveshare display panel itself is based on TFT technology, ensuring vibrant colors and sharp images, while the capacitive layer ensures accurate touch sensing without obstructing the display quality.

This 10.1-inch Raspberry Pi Touch Screen supports multiple operating systems, including Windows 10/8.1/8/7, Raspbian, Ubuntu, Kali, Retropie, and WIN10 IoT, with single-point touch compatibility. It is perfect for DIY projects, industrial applications, embedded systems, or as a secondary monitor for PCs.

Applications:

• Industrial Control
• Charging Pile
• Smart Home
• Medical
• Internet of Things
• Robot,
• Vehicle-mounted instruments,
• Vending instruments
• Intelligent CNC, cosmetic instruments

Features:

• Hardware resolution is 1024 x 600.
• GT7385: Touch Controller
• Touch Panel Type: Capacitive (10-Point Touch)
• Aspect Ratio (16:9)
• The glass panel is toughened to 6H hardness and has a 10-point capacitive touch.
• Fully laminated for enhanced touch.
• When used with the Raspberry Pi, it supports the Raspberry Pi OS, Ubuntu, Kali, and Retropie.
• When used as a computer monitor, it works with Windows 11/10/8.1/8/7.
• Features a 3.5mm headphone jack and a 4PIN HDMI audio interface.
• Common game platforms supported are the XBOX360 and Switch.
• To save power, the backlight can be turned off.

Package Includes:

• 1 x 10.1inch HDMI Capacitive Touch Screen LCD (E) 1024×600 Supports Raspberry Pi

Specifications:
