XL4015 DC-DC Step Down Adjustable Power Supply Module
XL4015 DC-DC Step Down Adjustable Power Supply Module
XL4015 DC-DC Step Down Adjustable Power Supply Module
The XL4015 power module is a DC to DC step-down (BUCK) power module that operates at a switching frequency of 180kHz. In such high frequency, it provides smaller-sized filter components compared with low frequency switching regulators.
This DC-DC switching buck converter is capable of driving a 5A load with excellent line and load regulation. The main switching component is XL4015, an adjustable output version switching regulator. It is an efficient switching regulator and the output efficiency is significantly higher in comparison with the popular boost regulators. At higher input voltages, the regulator operates at a switching frequency of 180kHz, thus allowing the overall board size to be smaller and space-saving. It is a high-power switching module with a toroidal ring inductor.
Learn more about how buck converters work in our beginner's guide, and check out our Beginner's Guide to Power Supply for DIY Projects for wiring tips and safety best practices.
Pinouts:
XL4015 Pinouts
Applications:
- DIY based power supply
- To serve the power requirements of high-power Audio-based circuits.
- High current applications with small space
Package Includes:
- 1 x XL4015 DC-DC
Specifications:
| Model | XL4015 |
| Frequency | 180 KHz |
| Dimensions | 3 x 2 x 1cms |
| Weight | 5 grams |
1. What is XL4015 Module?
The XL4015 Buck Module is a fixed frequency 180 kHz PWM buck (step-down) DC/DC module. Capable of driving 5A loads with high efficiency, low ripple and load regulation. Used as a step-down module with overcurrent protection. It can be used as a charger for lithium batteries.
2. How do I use XL4015 module?
A 230V to 30V step-down transformer is required to run the XL4015 DC-DC step-down power module. The output of the transformer is fed to the input of the rectifier diode as shown in the figure above. The output of the diode is fed directly to the input of the XL4015 module. The user can adjust the potentiometer to get the output voltage from 1.25V to 36V. However, the higher the input voltage, the higher the load current capability. Connect the regulated or unregulated input through the IN+ and IN- pins and adjust the output voltage using a potentiometer. Connect the load directly to the OUT+ and OUT- pins.
3. What are the uses of an XL4015 Module?
The XL4015 DC/DC buck module is used when the input voltage is higher than the output voltage of the buck field, such as battery, power transformer, DIY adjustable regulated power supply. It can be used in LiPo batteries also.
4. What is the maximum input/output voltage for the XL4015?
The XL4015 module typically accepts an input voltage range of 4.5V to 36V (up to 40V absolute max). It provides an adjustable output voltage from 1.25V to 36V. For optimal performance, ensure your input voltage is at least 1.5V higher than your desired output voltage.
5. Can it handle 5A+ continuous current?
The module is rated for a maximum peak current of 5A. However, for safe, continuous operation, it is highly recommended to keep the load at or below 3A to 4A. Pushing the absolute 5A limit for extended periods can cause excessive heat buildup and may trigger the built-in thermal shutdown.
6. Is a heatsink included or required for high loads?
A heatsink is not included in the package. While the module features built-in thermal shutdown protection, adding an aftermarket heatsink to the XL4015 IC is strongly recommended if you plan to draw currents above 3A or if there is a large voltage drop between input and output, to prevent overheating and ensure long-term reliability.
