XH-M120 PAM8610 Amplifier Board

XH-M120 PAM8610 Amplifier Board

Low stock: 1 left

Regular price Rs. 167
Regular price Rs. 339 Sale price Rs. 167
Sale Sold out 51% off
Incl. GST (No Hidden Charges)
Submit your Bulk Enquiry Here
Currently, people are actively viewing.
Trust Badge 1

Free shipping on Orders Above Rs 499/-

Fast Delivery

Trust Badge 2

Technical Support & Easy Returns

Trust Badge 3

Earn RC Coins on Every Purchase

Rewards

Trust Badge 4

Cash on Delivery Available

Cash Delivery

COUPON

RC100 FLAT ₹ 100/- OFF

When you shop for ₹ 2500 or more.Applicable on Checkout.

*Coupons are not applicable on Original Boards and Kits

  • The XH M120 Pam8610 amplifier board is designed to allow the device to drive the speaker directly.
  • This is a 15W dual channel amplifier board that needs a supply voltage of DC6 ~ 15V.
  • This amplifier board is integrated with a PAM8610 chip and a class audio amplifier.
  •  It offers low THD+N, allowing it to achieve high-quality sound reproduction.

XH-M120 PAM8610 Amplifier Board

The PAM8610 amplifier board is an all-new efficient amplifier board equipped with a 15W dual channel class D audio amplifier. This XH-M120 PAM8610 amplifier board is much more efficient and performs better than the Class AB amplifier boards.

This Pam8610 audio amplifier board helps save cost and PCB area by eliminating the need for a low-pass output filter. It also can extend the battery life and is ideal for portable applications.

Features:

  • Output Power: 2x15W (at 4Ω load), 2x10W (at 8Ω load)
  • Power Supply: Operates on a 7V to 15V DC power supply (12V recommended)
  • Efficiency: High efficiency (up to 90%)
  • Volume Control: 32 steps DC volume control with a range from +32dB to -75dB
  • Protection: Includes short-circuit, overheating, and over-current protection
  • Frequency Response: 20Hz to 15kHz
  • Size: 45mm x 48mm x 18mm
  • Low THD+N: Total Harmonic Distortion plus Noise (THD+N) of 0.1% for high-quality sound reproduction
  • Compact Design: Saves cost and board space by eliminating the need for a low-pass output filter

Applications:

  • DIY Audio Projects: Ideal for building custom audio systems and portable speakers.
  • Portable Applications: High efficiency and compact size make it suitable for battery-powered devices.
  • Home Audio Systems: Can be used to enhance home audio setups with high-quality sound.
  • Educational Projects: Useful for electronics and audio engineering students to learn about amplifier circuits.
  • Embedded Systems: Can be integrated into various embedded systems requiring audio amplification.
  • Prototyping: Great for prototyping audio-related projects due to its ease of use and versatility

Package Includes:

  • 1 x XH-M120 PAM8610 Amplifier Board

Features of the XH-M120 PAM8610 Amplifier Board

Model XH-M120
Number of Channels Dual Channel Amplifier Board
Chip Used PAM8610
Output Power 15W * 2
Supply Volatge DC6 ~ 15V
Work Class D
Dimensions 43mm x 47mm
Weight 15g
