Regular price
Rs. 185
Sale price
Rs. 185
Regular price
Rs. 240
You save Rs. 55
23% off
You save Rs. 55
Unit price
per
  • ⚡ Dispatched within 24 hours
  • 🚚 Free shipping on orders above Rs 500/-
  • 💰 Earn RC Coins on every purchase
  • 🛠️ Dedicated Technical Support Team
  • A safe and accurate voltage and current tester for troubleshooting electrical problems in automotive and household settings. Check for battery quality, automotive circuits, and charging systems.
  • A portable, general purpose digital volt meter multimeter to test wires, batteries, cells, fuses and other electrical components.
  • Built-in overload protector keeps the meter from any possible damage, Checks continuity of wires, fuses, and electrical components. Overload indicator and low battery indicator.
  • Red and black leads to test electrical system components including diodes, transistors, wires, fuses, and battery testing on electrical equipment.
  • Includes large, easy-to-read LCD screen that measures 3-1/2 digits and accurately measures resistance, current and voltage with maximum reading up to 1999.

Digital Multimeter with Probe

The digital multimeter, DMM, is one of the most common items of test equipment used in the electronics industry today. While there are many other items of test equipment that are available, the multimeter is able to provide excellent readings of the basic measurements of amps, volts and ohms.

In addition to this the fact that these digital multimeters use digital and logic technology, means that the use of integrated circuits rather than analog techniques enables many new test features to be embedded in the design.

Note: To run a test to measure voltage, you connect the red multimeter lead to the positive side of the battery or circuit that you're testing and the black lead to the negative or ground side and set the dial to the voltage range you expect.

Applications:

  • Electrical measurements
  • AC and DC voltage
  • AC and DC current
  • Resistance
  • Voltmeter
  • Ammeter, and ohmmeter
  • Voltage fluctuations in homes or offices.

Package Includes:

  • 1 x Digital Multimeter

Specifications:

AC Voltage Ranges 750V, 200V
DC Voltage Ranges 1000V, 200V, 20V, 2V, 200mV
DC Current Ranges 10A, 200mA, 20mA, 2mA
Resistance Ranges 2000 kOHM, 200 kOHM, 20 kOHM, 2 kOHM, 200 OHM
Square Wave Generator 5V p-p 50Hz
Dimensions 12.6cm x 7cm x 2.8cm
Weight  150 grams



Frequently Asked Questions

1. How do you set up a digital multimeter?

  • Plug the probe wires into the multimeter and set the dial to continuity. Insert the red plug into the terminal labeled V, Ω, or with the continuity sign, which looks like a sound wave. Connect the black plug to the COM port. Turn the dial to the image that resembles a sound wave.

2. What are the symbols on a multimeter?

  • A multimeter measures resistance by sending a small electric current through the circuit. The symbols for the unit of resistance is -
    • Ω = Ohms.
    • kΩ = Kilohms.
    • MΩ = Mega ohms.

3. What is digital multimeter used for?

  • A digital multimeter, or DMM, measures and verifies multiple electrical stimuli, including voltage, current, and resistance. It combines the functions of a voltmeter, ammeter, and ohmmeter and is used on a daily basis by technicians and electrical engineers.

4. How do I test wires with a multimeter?

  • Set a multimeter to measure voltage. Insert a probe into each slot and measure the line voltage. A properly functioning outlet reads 110 to 120 volts. Check the wiring and the outlet if there is no reading.
