The Arduino Portenta Hat Carrier is a reliable and robust Portenta Carrier board for Arduino, designed to transform your Arduino Portenta board (specifically the X8, but also compatible with H7 and C33) into a versatile industrial single-board computer.

This Portenta Hat Carrier board seamlessly bridges the Arduino Portenta ecosystem with the extensive range of Raspberry Pi® Hats and cameras, opening up new avenues for developing advanced commercial and industrial solutions.

It offers straightforward access to a suite of essential peripherals including a CAN bus interface, Ethernet connectivity (Gigabit with Portenta X8, 100Mbit with H7/C33), a USB-A port, and a microSD card slot for data logging or system storage.

Engineered for both rapid prototyping and scalable deployments, the Arduino Portenta Hat Carrier extends the capabilities of the Portenta System on Modules by incorporating a 40-pin Raspberry Pi compatible GPIO header, a dedicated MIPI CSI camera connector for machine vision tasks, and an additional 16 analog I/O pins for interfacing with sensors and actuators.

For enhanced development and reliability, it includes dedicated JTAG pins for debugging and a PWM fan connector to manage thermal performance under demanding workloads, making it an ideal choice for building automation, machine monitoring, and robotics applications.

Features:

• Compatible with Portenta X8, H7, and C33 System on Modules.

• Standard 40-pin header for broad Raspberry Pi® HAT compatibility.

• Onboard high-speed CAN FD transceiver for industrial communication.

• Ethernet port: Gigabit with Portenta X8, 100Mbit with H7/C33.

• USB-A female connector for peripherals or data logging.

• MicroSD card slot for data storage and media operations.

• MIPI CSI camera connector for machine vision applications.

• 16 additional analog I/O pins for sensors and actuators.

• Dedicated 10-pin JTAG connector for efficient debugging.

• PWM fan connector for active thermal management.

• Screw terminal block provided for power and CAN bus connections.

• Wide operating temperature range: -40°C to +85°C.

• Facilitates Linux prototyping with Portenta X8.

• Enables integrated real-time MCU solutions with Portenta.

• Designed for robotics, industrial, and building automation projects.

Package Includes:

• 1 x Official Arduino Portenta Hat Carrier Development Board
