NE555 Pulse Frequency Duty Cycle Adjustable Module

Rs. 45
Rs. 69
Rs. 45
Save Rs. 24
(-35%)
Incl. GST (No Hidden Charges) Found a better price?
Please hurry! Only 104 left in stock
SKU: TIFEC0118
  • Used as a square wave signal generator to generate square wave signals for experimental development.
  • Used to generate a square wave signal that drives the stepper motor driver.
  • Can be used to generate an adjustable pulse, for for MCU and to control circuitry associated.
  • The output current can be 15 MA around; when 12V power supply, the output current can 35 MA around
  • Output with LED indication(low level, LED will on; high level, LED will off; low frequency, the LED flashes).
  • Max Output Current: >= ≥15MA (5V power supply, V-PP greater than 50%), >=35MA (12V power supply, V-PP greater than 50%)
FLAT ₹ 100/- OFF
RC100
COPY CODE

When you shop for ₹2500 or more. Applicable at checkout.
*Coupons are not applicable on Original Boards and Kits.

Free shipping on Orders Above Rs 499/-

Technical Support & Easy Returns

Same Day Shipping

Earn RC Coins on Every Purchase

Cash on Delivery Available

Robocraze Academy Limited Time Offer

Bulk Order?

For Best Price Contact on WhatsApp for bulk discounts!
Or Fill the Form Below

Submit your Bulk Enquiry Here
Enter the Captcha
Reload
Robocraze Academy Limited Time Offer
NE555 Pulse Frequency Duty Cycle Adjustable Module – NE555 relay for pulse control. -Relay Module -Robocraze
NE555 Pulse Frequency Duty Cycle Adjustable Module
Rs. 69 Rs. 45
NE555 Pulse Frequency Duty Cycle Adjustable Module – NE555 relay for pulse control. -Relay Module -Robocraze
NE555 Pulse Frequency Duty Cycle Adjustable Module – NE555 relay for pulse control. -Relay Module -Robocraze
NE555 Pulse Frequency Duty Cycle Adjustable Module – NE555 relay for pulse control. -Relay Module -Robocraze
NE555 Pulse Frequency Duty Cycle Adjustable Module – NE555 relay for pulse control. -Relay Module -Robocraze
NE555 Pulse Frequency Duty Cycle Adjustable Module – NE555 relay for pulse control. -Relay Module -Robocraze

NE555 Pulse Frequency Duty Cycle Adjustable Module

Rs. 69 Rs. 45
Description

NE555 Pulse Frequency Duty Cycle Adjustable Module

NE555 Pulse Frequency Duty Cycle Adjustable Module Square Wave Signal Generator is 5 V square wave signal generator. It generates a square wave signal used for experimental development. Also, use to drive a stepper motor for generating a square wave drive signal. The output duty cycle can fine-tune. Duty cycle and frequency is not separately adjustable, adjusting the duty cycle will change the frequency.

Applications:

  • As a square wave signal generator generates a square wave signal used for experimental development.

  • Used to drive a stepper motor for generating a square wave drive signal.

  • Generate an adjustable pulse for MCU.

  • Generate an adjustable pulse, to control circuitry associated.

Specifications

Package Includes:

  • 1 x NE555 Pulse Frequency Duty Cycle Adjustable Module Square Wave Signal Generator

Specifications:

Main chip NE555
Input Voltage 5V-15V DC
Input current  >=100 MA
Output amplitude 4.2V V-PP to 11.4V V-PP
Maximum output current >=15MA
Dimensions  31mm x 22mm
Weight  5 grams
FAQ

1. What is a NE555 Pulse Frequency Duty Cycle Adjustable Module?

  • This square wave generator uses two potentiometers with variable frequency and duty cycle. It can drive square wave signals for stepper motors and can be used to control motors (PWM generators), and adjust the brightness of light bulbs and LEDs or timers. It also has an adjustable pulse control circuit. This module uses the NE555 integrated circuit to generate a square wave signal to generate adjustable pulses for use with the MCU.

2. What are the advantages of the NE555 Pulse Frequency Duty Cycle Adjustable Module?

  • Advantages of  NE555 Pulse Frequency Duty Cycle Adjustable Module:
    • Output level selectable frequency range, the output frequency is more continuously adjustable.
    • The output duty cycle can be fine-tuned.
    • The duty cycle and frequency cannot be adjusted independently.
    • Adjusting the duty cycle will change the frequency.
    • The output frequency is adjustable.
