Mornsun LIF240-10B12R2S AC/DC 240W DIN-Rail Power Supply
Mornsun LIF240-10B12R2S AC/DC 240W DIN-Rail Power Supply
Out of stock
Couldn't load pickup availability
BEST COUPON FOR YOU
When you shop for ₹ 10000 or more.Applicable on Checkout.
*Coupons are not applicable on Original Boards and Kits
- Universal input voltage of 85 - 264VAC or 120 - 370VDC
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range of -40℃ to +70℃
- High efficiency and high reliability
- Built-in active PFC function
- 150% peak load output for 3 seconds
- LED indicator for power on
- Output short circuit, over-current, over-voltage, and over-temperature protection
- Safety according to IEC/UL62368, UL508, EN61558
This product is not available for store pickup. Apologies for the inconvenience caused
Mornsun LIF240-10B12R2S AC/DC 240W DIN-Rail Power Supply
The LIF240-10B12R2S is an energy efficient, green AC-DC converter from Mornsun. It is a DIN-rail mounted power supply that offers a high level of stability and immunity to noise. It is ideal for use in industrial control equipment, machinery, and other industrial equipment in a variety of harsh environments. The LIF240-10B12R2S is lightweight and compact, making it easy to install and save space. It is also compliant with international EMC and safety standards.
Features:
- Energy efficient
- Green
- DIN-rail mounted
- High level of stability and immunity to noise
- Ideal for use in industrial control equipment, machinery, and other industrial equipment in a variety of harsh environments
- Lightweight and compact
- Compliant with international EMC and safety standards
If you are looking for an energy efficient, green AC-DC converter for your industrial application, the LIF240-10B12R2S is a great option. It offers a high level of performance and reliability, and it is compliant with international standards.
check out : Mornsun LIF240-10B24R2S AC/DC 240W DIN-Rail Power Supply
Note:
- Unless otherwise specified, parameters in this datasheet were measured under the conditions of Ta=25℃, humidity<75%RH with nominal input voltage and rated output load
- The room temperature derating of 5℃/1000m is needed for operating altitude greater than 2000m
- All index testing methods in this datasheet are based on our company's corporate standards
- In order to improve the efficiency at high input voltage, there will be audible noise generated, but it does not affect product performance and reliability
- The out case needs to be connected to the earth ( )of system when the terminal equipment in operating
- The output voltage can be adjusted by the ADJ, clockwise to increase
- Our products shall be classified according to ISO14001 and related environmental laws and regulations and shall be handled by qualified units
- The power supply is considered a component which will be installed into the final equipment. All EMC tests should be confirmed with the final equipment
Package Includes:
1 x Mornsun LIF240-10B12R2S AC/DC 240W DIN-Rail Power Supply
Specifications
| Type | DIN Rail Single Output |
| Output Power | 192W |
| Series | LIF240-10B |
| Part Number | LIF240-10B12R2S |
| Mount | DIN-Rail |
| IP Level | Non-Waterproof |
| Output Voltage | 12V |
| Output Current | 16A |
