M5StickV K210 AI Camera (without wifi)
M5StickV K210 AI Camera (without wifi)
M5StickV K210 AI Camera (without wifi)
  • Load image into Gallery viewer, M5StickV K210 AI Camera (without wifi)
  • Load image into Gallery viewer, M5StickV K210 AI Camera (without wifi)
  • Load image into Gallery viewer, M5StickV K210 AI Camera (without wifi)

M5StickV K210 AI Camera (without wifi)

Regular price
Rs. 5,149
Sale price
Rs. 5,149
Regular price
Sold out
Unit price
per
Tax included. Shipping calculated at checkout.

  • Dual-Core 64-bit RISC-V RV64IMAFDC (RV64GC) CPU / 400Mhz(Normal)
  • Dual Independent Double Precision FPU
  • Neural Network Processor(KPU) / 0.8Tops
  • Field-Programmable IO Array (FPIOA)
  • Dual hardware 512-point 16bit Complex FFT
  • SPI, I2C, UART, I2S, RTC, PWM, Timer Support
  • AES, SHA256 Accelerator
  • Direct Memory Access Controller (DMAC)
  • Micropython Support
  • Firmware encryption support
  • Case Material: PC + ABS
Also checkout M5 Stack Development Kits, Sensors&Hats, Cameras and Modules collection

M5StickV K210 AI Camera (without wifi)

M5Stack recently launched the new AIoT(AI+IoT) Camera powered by Kendryte K210 -an edge computing system-on-chip(SoC) with dual-core 64bit RISC-V CPU and advanced neural network processor.

M5StickV AI Camera possesses machine vision capabilities, equips OmniVision OV7740 image sensor, adopts OmniPixel®3-HS technology, provides optimum low light sensitivity, supports various vision identification capabilities. (e.g. Real-time acquisition of the size, type, and coordinates of the detected target ) In addition to an OV7740 sensor, M5StickV features more hardware resources such as a speaker with built-in I2S Class-D DAC, IPS screen, 6-axis IMU, 200mAh Li-po battery, and more.

It is able to perform convolutional neural network calculations at low power consumption, so M5StickV will be a good zero-threshold machine vision embedded solution. It is in support of MicroPython, which makes your code to be more concise when you use M5stick-V for programming.

Switching operations

Power on: Long press power button for 2 seconds
Power off: Short press power button for 6 seconds

Applications:

  • Face recognition/detection
  • Object detection/classification
  • Obtaining the size and coordinates of the target in real-time
  • Obtaining the type of detected target in real-time
  • Shape recognition
  • Video/Display
  • Game simulator

Package Includes:

1x M5StickV
1x USB Type-C(100cm)
1x Bracket
1x HEX KEY

Specifications:

Kendryte K210 Dual core 64-bit RISC-V RV64IMAFDC (RV64GC) CPU / 400Mhz(Normal)
SRAM 8MiB
Flash 16M
Power input 5V @ 500mA
KPU Parameter size of neural network 5.5MiB - 5.9MiB
Port TypeC x 1, GROVE(I2C+I/0+UART) x 1
RGB LED RGBW x 1
Button Custom button x 2
IPS screen 1.14 TFT, 135*240, ST7789
Camera OV7740(30W pixels)
FOV 55deg
PMU AXP192
Battery 200mAh
External storage TF-card(microSD)
MEMS MPU6886
Dimension 48*24*22mm
Weight 82gm
