EMAX ECO II 2004 3000KV Brushless Motor for Mini FPV Drones with High RPM
Couldn't load pickup availability
The EMAX ECO II 2004 3000KV Brushless Motor is a high-performance, high speed brushless motor built specifically for mini FPV drones and racing quads.
Featuring a redesigned, reinforced structure with a rounded architecture and sleek mirror-polished finish, it ensures exceptional durability and performance under demanding conditions.
With powerful N52SH arc magnets, the motor delivers superior torque, faster RPMs, and highly responsive throttle control, making it perfect for freestyle, cinematic, or racing drone applications.
Combining cutting-edge design, reliability, and affordability, this brushless motor for drone enthusiasts stands out as the next evolution in compact brushless motor technology.
| Specification | Details |
|---|---|
| Motor Type | Brushless Motor |
| Motor KV | 3000 RPM/V |
| Compatible LiPo Batteries | 4S to 6S |
| Framework | 12N14P |
| Maximum Thrust | 1170 g (on 4S) |
| Peak Current | 32 A |
| Compatible Propeller | 4" – 5" inch |
| Bearing Shaft | 3 mm |
| Additional Specs | Bolt Pattern: M2 (12×12 mm) |
| Prop Adapter Shaft Thread | 1.5 mm |
