Package Includes:
- 1x Chassis
- 1x Ultrasonic Sensor
- 1xBattery Holder
- 2x Wheels
- 4x M3*8mm Screws
- 2x M3*5mm Copper Column
- 2x Side Acrylic Plates
- 1x Front Acrylic Plates
- 1x Screwdriver
- 2x 4 Pin Crowtail Cable
- 1x Type C Cable x1
- 1x Infrared remote control
- 1x Instructions & Line Track Map
Specifications:
Processor
|
Esp32-Wrover-b?8MB?
|
Programmatically
|
Letscode, Arduino, Micropython
|
Control method
|
Bluetooth Remote Control/Infrared Remote Control
|
Input
|
Button, Light sensor, Infrared Receiving Module, Ultrasonic Sensor, Line Tracking Sensor
|
Output
|
Buzzer, Programmable RGB Light, Motor
|
Wifi&Bluetooth
|
Yes
|
Light sensor
|
Can realize the function of chasing light or avoiding light
|
Ultrasonic Sensor
|
When an obstacle is detected, the driving route of the car can be corrected to avoid the obstacle
|
Line Tracking Sensor
|
Can make the car move along the dark/black lines, intelligently judge and correct the driving path
|
Buzzer
|
Can make the car sound/whistle, bringing a more direct sensory experience
|
Programmable RGB Light
|
Through programming, it can show colorful lights in different scenes
|
Infrared receiver
|
Receive infrared remote control signals to realize remote control
|
Interface
|
Type c x1, I2C port x1, A/D port x1
|
Motor type
|
GA12-N20 Micro DC Gear Motor
|
Work Temperature
|
-10?~+55?
|
Power supply
|
1.5V dry batteries x4?Battery not included?
|
Battery life
|
1.5 hour
|
Dimension
|
128*92*64mm
|
Weight
|
900g
|
