4 Channel (I2C or SPI) 3.3V-5V Bi-Directional Logic Level Converter

4 Channel (I2C or SPI) 3.3V-5V Bi-Directional Logic Level Converter

7

Rs. 16
Rs. 19 Rs. 16
Sale Sold out 16% off
or ₹ 15 + alt-pay-logo 1 points
Incl. GST (No Hidden Charges)
Submit your Bulk Enquiry Here
Currently, 22 people are actively viewing.
Trust Badge 1
Same Day Shipping
If Ordered within 6 Hours and 4 Minutes
Trust Badge 2

Technical Support & Easy Returns

Trust Badge 3

Earn RC Coins on Every Purchase

Rewards

Trust Badge 4

Cash on Delivery Available

Cash Delivery

COUPON

RC100 FLAT ₹ 100/- OFF

When you shop for ₹ 2500 or more.Applicable on Checkout.

*Coupons are not applicable on Original Boards and Kits

  • This is 4 Channel 3.3V-5V Bi-Directional Logic Level Converter
  • Mutual transform between 5V TTL and 3.3V TTL
  • Four channels of logic and high voltage low voltage logic can two-way transform
  • Portable and lightness, with 2 rows 6 pin contact pins
  • Level Converter- 4 Channel Compatible with the bread plate, can be used directly put on the breadboard
  • 4 Channel Module (great for I2C or SPI) and will work with all microcontrollers, Arduino, Raspberry Pi, Intel Edison, NXP Mbed
  • This is a great addition to your hobby craft tool kit Perfect product for your safety and lab supply Good for many applications include industrial, laboratory, personal and hobbies.

4 Channel (I2C or SPI) 3.3V-5V Bi-Directional Logic Level Converter

If you've ever tried to connect a 3.3V device to a 5v system, you know what a challenge it can be. The bi-directional logic level converter is a small device that safely steps down 5v signals to 3.3V and steps up 3.3V to 5v at the same time. This level converter also works with 2.8V and 1.8V devices. What separates this logic level converter from our previous versions is that you can successfully set your high and low voltages and step up and down between them safely on the same channel. Each level converter has the capability of converting 4 pins on the high side to 4 pins on the low side with two inputs and two outputs provided for each side. The level converter is very easy to use. The board needs to be powered from the two voltage sources (high voltage and low voltage) that your system is using. High voltage (5v for example) to the 'hv' pin, low voltage (3.3V for example) to 'lv', and ground from the system to the 'gnd' pin logic level shifter bi-directional with 4 channels between high logic and low logic small module with 1.3Cm x 1.5Cm with 2 rows of 6 pin compatible with a breadboard, can be directly used in breadboard usage: for example, high voltage is 5v, low voltage is 3.3V hv connect with 5v power supply lv connect with 3.3V power supply and connect the power negative pole lvx input/output 3.3V TTL hvx input/output 5v ttl bi-directional transform between lvx and tvx

Features:

  • Mutual transform between 5V TTL and 3.3V TTL
  • Four channels of logic and high voltage low voltage logic can two-way transform
  • Portable and light, with 2 rows 6 pin contact pins
  • Level Converter- 4 Channel Compatible with the bread plate, can be used directly put on the breadboard
  • 4 Channel Module (great for I2C or SPI) and will work with all microcontrollers, Arduino, Raspberry Pi, Intel Edison, NXP Mbed

Also check 2 Channel Logic Level Converter (I2C, UART, 5V-3.3V) available on the Robocraze website. It is a small device designed to safely step down 5V signals to 3.3V and simultaneously step up 3.3V to 5V. The converter is bi-directional and works with 2.8V and 1.8V devices as well. It has two inputs and two outputs for each side, allowing the conversion of 4 pins on the high side to 4 pins on the low side.

Package includes:

  • 1 x bi-directional transform module 2 x rows of pins.

Specifications

Number of channels 4
Operating Voltage 2.8V - 6V
Length 16mm
Width 13mm
Height 3mm
Weight 2gm
  • All orders confirmed before 3 pm IST are shipped on the
    same day, barring rare pickup delays on holidays or disturbances
  • Delivery time in Metro cities is 1-3 days, Others it is
    3-7 days. It varies based on location, reliant on courier services
  • Return window: 7 days from receipt unless stated
    otherwise. No refunds/replacements after
  • Returns only for non-working/damaged products are accepted
  • Initiate return requests to our customer service team via Support ticket or contact us at +91-8123057137
  • Refunds are processed within 3-4 working days post inspection and approval.

For more details, please check our Shipping and Return Policy

View full details
