230V 25W Soldron Soldering Iron
People Also Buy
230V 25W Soldron Soldering Iron
This is 230V 25W soldering iron from SOLDRON. If you are a student or hobbyist and you are looking for a good general-purpose Soldering Iron then this 25W soldron Soldering Iron is perfect for you. Even we have been using this Soldering iron from the start and it is one of the best soldering iron for electronics that you can get at this price range.
This 25W soldering iron is ergonomically designed tri-grip handle with ridges for comfortable slip-free handling Gravity-centered unit designed to tilt easier while working at the high-temperature rating. Ringed bit for easy for changing a superior quality product developed element for fast and consistent heating.
One must be aware of the soldering tools that are crucial during the process in order to solder the necessary elements , and the soldering tools are:
Features of 230V 25W Soldron Soldering Iron :
- The workhorse of electronic industries. The highest and most well-liked product.
- For all electronic applications, general purpose
- Within a few seconds reaches peak working temperature.
- Regulates tip temperature consistently.
- Low leakage current.
- Safe for use with sensitive and specialized Components.
- Highest heat transfer effectiveness.
- Insulating nylon handle with high-quality grip
- High-grade building materials
- Hook offered for hanging
- Easy to use, portable, and lightweight
- A long-lasting heating element that is built to last.
Applications:
- PCB assembly & repair
- Electricals soldering
- Jewellery
Package Includes:
- 25W Soldering Iron
Specifications
| Operating Voltage | 230 VAC |
| Power Rating | 25W |
| Bit Type | Chisel 25W Rated |
| Max Temperature(°C) | 380 |
| Dimensions | 11 x 9 x 5cms |
| Weight | 150 grams |
1. How hot is a 25-watt soldering iron?
- Perfect for integrated circuit work and minor repairs, this 25-watt soldering iron produces temperatures up to 250ºC. Replaceable screw-in 5/32" tip switches out quickly and conveniently.
2. Is a soldering iron with a 25-watt power supply sufficient?
- For most PCB soldering, 25W is sufficient. If you hold the iron on for more than a second at a higher temperature, the traces on the circuit board will melt. A 15W iron would be ideal for very small-scale work (such as SMT). Unless you're soldering something to a very large piece of metal, 25W is more than enough.
3. Why is my soldering iron not hot enough?
- The majority of soldering irons are powered by electricity, which will stop working if the circuit is broken. If your soldering iron isn't producing heat, it's most likely due to a short in the electrical circuit, which could be caused by a faulty iron connection or a heating element failure.
4. How do I choose a soldering iron?
- Soldering iron with at least 25 watts of power is recommended. Low-wattage soldering irons take longer to heat up and do not maintain a consistent temperature. Compatible tips: the iron's tips should be replaceable, and the iron should work with a wide range of tips.
5. What makes a soldering iron different from a soldering gun?
- A soldering gun, which is shaped like a pistol and can be operated with one hand, is used to join metal surfaces. A soldering iron is a wand-shaped tool with a heated metal tip that is used to join two pieces of metal.
