7Semi ADS1015 I2C 4-Channel 12bit ADC Breakout Board - Buy Online in India

7Semi ADS1015 I2C 4-Channel 12bit ADC Breakout Board

Rs. 223
Rs. 289
Rs. 223
Save Rs. 66
Incl. GST (No Hidden Charges) Found a better price?
Please hurry! Only 0 left in stock

We’ll notify you once the product is back in stock.

SKU: TIFCC0357
  • High-precision ADS1015 12-bit ADC for accurate analog-to-digital conversion.
  • Supports I2C ADC 4 channel communication for easy microcontroller integration.
  • 12-bit resolution with up to 3.3 kSPS sampling rate.
  • Built-in Programmable Gain Amplifier (PGA) for flexible signal scaling.
  • Operates on 2.0V to 5.5V supply voltage, compatible with various sensors.
  • Ideal for electronics, IoT projects, and sensor measurement applications.
BEST COUPON
RC100
COPY CODE
When you shop for ₹ 2,500 required. Applicable at Checkout.
*Coupons are not applicable on Original Boards and Kits

Why Buy From Robocraze

Free shipping on Orders Above Rs 499/-

Technical Support & Easy Returns

Same Day Shipping

Earn RC Coins on Every Purchase

Cash on Delivery Available

Robocraze Academy Limited Time Offer

Bulk Order?

For Best Price Contact on WhatsApp for bulk discounts!
Or Fill the Form Below

Submit your Bulk Enquiry Here
Enter the Captcha
Reload
Robocraze Academy Limited Time Offer
7Semi ADS1015 I2C 4-Channel 12bit ADC Breakout Board -Electronic Modules -Breakout Boards -Robocraze
7Semi ADS1015 I2C 4-Channel 12bit ADC Breakout Board
Rs. 289 Rs. 223
7Semi ADS1015 I2C 4-Channel 12bit ADC Breakout Board -Electronic Modules -Breakout Boards -Robocraze
7Semi ADS1015 I2C 4-Channel 12bit ADC Breakout Board -Electronic Modules -Breakout Boards -Robocraze
7Semi ADS1015 I2C 4-Channel 12bit ADC Breakout Board -Electronic Modules -Breakout Boards -Robocraze

7Semi ADS1015 I2C 4-Channel 12bit ADC Breakout Board

Rs. 289 Rs. 223
Description

7Semi ADS1015 I2C 4-Channel 12bit ADC Breakout Board

The 7Semi ADS1015 I2C 4-Channel 12bit ADC Breakout Board is built around the Texas Instruments ADS1015, offering high-precision 12-bit analog-to-digital conversion at speeds up to 3.3 kSPS. With its i2c ADC 4 channel interface, the board allows seamless integration with microcontrollers and single-board computers.

The onboard programmable gain amplifier (PGA) ensures accurate readings across a range of sensor signals. Operating on a versatile 2.0V to 5.5V supply, this ADS1015 12-bit ADC board is perfect for electronics enthusiasts, IoT projects, and any application requiring reliable analog signal measurement.

Features:

  • 12-Bit Noise-Free Resolution: Achieve higher precision with little noise interference, resulting in exact readings under all settings.
  • Wide Supply Range (2.0 V to 5.5 V): This board's flexible voltage options make it compatible with a variety of power sources.
  • Low Power Consumption: Continuous conversion mode consumes only 150 µA, making it ideal for battery-powered applications with high energy efficiency.
  • Programmable Data Rate: Change the sampling speed from 128 SPS to 3.3 kSPS to suit your measurement requirements.
  • Internal low-drift voltage reference and oscillator: Provides stable and consistent performance throughout time, which is critical for long-term projects.
  • I2C Interface with Four Pin-Selectable Addresses: Makes integration easier and enables multiple devices to connect seamlessly within your system.
  • Four single-ended or two differential inputs provide diverse input possibilities for various measurement combinations.
  • Programmable Gain Amplifier (PGA): Improves signal processing, allowing for precise readings over a wide range of input levels.
  • Compact and Space-Saving Design: Ideal for applications with limited space, without sacrificing functionality.

Connection Diagram with Arduino:

Connection Diagram
Specifications

Package Includes:

  • 1 x 7Semi ADS1015 I2C 4-Channel 12bit ADC Breakout Board

Specifications:

Specification Details
ADC Resolution 12-bit
Number of Channels 4 (Differential/Single-Ended)
Communication Interface I2C
Sampling Rate Up to 3.3 kSPS
Programmable Gain Amplifier (PGA) Yes
Supply Voltage 2.0V – 5.5V
Operating Temperature -40°C to 85°C
Compatible With Arduino, Raspberry Pi, ESP32, other MCUs
