4.3-inch IPS display with 800 × 480 hardware resolution for clear, detailed visuals.
5-point capacitive touch with a 6H tempered glass panel for responsive and durable operation.
HDMI display interface with USB touch interface, keeping the Raspberry Pi GPIO pins free.
160° viewing angle provides comfortable viewing from different positions.
Supports Raspberry Pi OS, Ubuntu, Kali, and Retropie on Raspberry Pi.
Also works with Windows 11/10/8.1/8/7, Jetson Nano, and compatible game consoles.
Includes 3.5mm audio output and a speaker connector for HDMI audio applications.

Bulk Order?

For Best Price Contact on WhatsApp for bulk discounts!
Or Fill the Form Below

Submit your Bulk Enquiry Here

First Name *

Last Name *

Email *

Phone *

+91

Company / Client

GST *

Materials List

File(s) size limit is 20MB. Max 3 files.

Choose Categories * (select one or more)

Select Categories

STEM Kits Development Boards Electronic Components Drone 3D Printers/Pens Sensors Batteries & Power Supply Tools & Instruments

Enter the Captcha *

Reload Captcha

Waveshare 800×480 4.3-Inch HDMI IPS Capacitive Touch LCD Display (B) for Raspberry Pi

~~Rs 7,349/-~~ Rs 5,139/-

Quantity:

Waveshare 800×480 4.3-Inch HDMI IPS Capacitive Touch LCD Display (B) for Raspberry Pi

~~Rs 7,349/-~~ Rs 5,139/-

Description
Specifications
Additional Resources
Warranty
Shipping & Return

Description

Waveshare 800×480 4.3-Inch HDMI IPS Capacitive Touch LCD Display (B) for Raspberry Pi

The Waveshare 4.3-Inch HDMI IPS Capacitive Touch LCD Display (B) is a compact Raspberry Pi touchscreen display designed for projects that need a responsive visual interface without occupying the Raspberry Pi’s 40-pin GPIO header. It features a 4.3-inch IPS panel with an 800 × 480 hardware resolution, a 160° viewing angle, and a 5-point capacitive touch panel protected by a tempered glass surface with 6H hardness.

The display connects through HDMI, while touch input is handled through USB, making it suitable for Raspberry Pi applications, mini PCs, embedded projects, interactive dashboards, and compact control interfaces.

When used with Raspberry Pi, it supports Raspberry Pi OS, Ubuntu, Kali, and Retropie, while Windows systems from Windows 7 through Windows 11 are also supported. The built-in OSD menu allows adjustments such as brightness and contrast, while the 3.5mm audio jack and 4-pin speaker interface provide options for HDMI audio output.

Features:

4.3-inch IPS screen with 800 x 480 hardware resolution.
5-point capacitive touch control, tempered glass panel, and hardness of up to 6H.
It works with Raspberry Pi OS, Ubuntu, Kali, and Retropie platforms.
When used as a computer monitor, it supports Windows 11/10/8.1/8/7 with five-point touch.
OSD menu in multiple languages, including power management, brightness/contrast adjustment, and so on.
3.5mm audio jack, speaker connector, and HDMI audio output.

Specifications

Package Includes:

1 x 4.3inch HDMI LCD (B)
1 x HDMI cable
1 x USB-A to Micro-B cable
1 x HDMI Adapter (B)
1 x USB Adapter (B)
1 x HDMI Adapter (C)
1 x USB Adapter (C)
1 x Screws pack

Specifications:

Specification	Details
Model	4.3inch HDMI LCD (B)
Display Size	4.3 Inches
Resolution	800 × 480 Pixels
Display Type	IPS LCD
Touch Type	5-Point Capacitive Touch
Touch Surface	6H Tempered Glass
Interface	HDMI + USB
Viewing Angle	160°
Audio	3.5mm Audio Jack + Speaker Interface
Raspberry Pi Support	Raspberry Pi OS, Ubuntu, Kali, Retropie
Windows Support	Windows 7/8/8.1/10/11
GPIO Usage	Does not occupy Raspberry Pi GPIO pins
