Waveshare 3.5-Inch 480×320 SPI Resistive Touch LCD Display (C) for Raspberry Pi - Buy Online in India
Waveshare 3.5-Inch 480×320 SPI Resistive Touch LCD Display (C) for Raspberry Pi
- Rs 1,989/-
- Rs 1,989/-
-
Rs 2,844/-
- 30%
Save Rs 855/-
RC REWARDS
Earn
19
RC Coins
on this order
Incl. GST (No Hidden Charges)
Found a better price?
Let us know!
We'll try to match the price for you
Please hurry! Only 0 left in stock
We’ll notify you once the product is back in stock.
SKU:
TIFDP0121
Couldn't load pickup availability
Waveshare 3.5-Inch 480×320 SPI Resistive Touch LCD Display (C) for Raspberry Pi
Waveshare 3.5-Inch 480×320 SPI Resistive Touch LCD Display (C) for Raspberry Pi
Waveshare 3.5-Inch 480×320 SPI Resistive Touch LCD Display (C) for Raspberry Pi
The Waveshare 3.5-Inch 480×320 SPI Resistive Touch LCD Display (C) is a compact Raspberry Pi touch screen display designed for interactive embedded projects, portable systems, DIY electronics, and Raspberry Pi applications. It features a 3.5-inch TFT panel with a 480×320 resolution and uses a 125MHz high-speed SPI interface for display communication, helping deliver clear and stable visuals.
The display also provides resistive touch control through SPI, allowing users to interact directly with supported Raspberry Pi applications. It connects through the Raspberry Pi GPIO interface and is compatible with all versions of Raspberry Pi computers.
Driver support is available for Raspbian, Ubuntu MATE, Kali, and RetroPie, while the FBCP software driver enables software resolution adjustment and dual-display operation at approximately 50Hz refresh rate. Its compact size matches the Raspberry Pi 3, Raspberry Pi 4, and Raspberry Pi 5 form factor, making it a practical 3.5-inch SPI LCD display for Raspberry Pi projects where a small interactive screen is required.
Features:
- 480 x 320 hardware resolution.
- Resistive touch control
- Compatible with any version of the Raspberry Pi and can be connected directly into it.
- Supports 125MHz high-speed SPI signal transmission, with a crisp and steady display.
- Provides drivers (supporting Raspberry Pi OS, Ubuntu, Kali, and Retropie platforms).
- Supports FBCP software driver, allows for software resolution and dual-screen display.
- The same size as your Raspberry Pi 3 / 4 / 5.
- A carefully designed gold immersion process
Package Includes:
- 1 x 3.5inch RPi LCD (C)
- 1 x Touch pen
- 1 x RPi screws pack (2pcs)
Specifications:
| Specification | Details |
|---|---|
| Display Size | 3.5 Inches |
| Resolution | 480 × 320 Pixels |
| Display Type | TFT LCD |
| Touch Type | Resistive Touch |
| Interface | SPI |
| SPI Speed | Up to 125 MHz |
| Touch Interface | SPI |
| Compatibility | Raspberry Pi 40-Pin GPIO |
| Supported OS | Raspbian, Ubuntu MATE, Kali, RetroPie |
| Refresh Rate | Up to 50 Hz with FBCP |
| Driver | FBCP Software Driver |
| Compatible Raspberry Pi | Raspberry Pi 3, 4, 5 & other 40-pin models |
Warranty Coverage:
This product comes with a 1-year manufacturer warranty from the date of purchase, covering manufacturing defects only.
Warranty Void If:
The product shows signs of physical damage, mishandling, exposure to water/moisture, fire, natural calamities, unauthorized repairs, improper storage near heat or direct sunlight, or alteration in any way.
