10.1-inch IPS touchscreen display with a 1280 × 800 hardware resolution for clear, detailed visuals.
Uses a DSI interface for direct connection to compatible Raspberry Pi boards.
Features 10-point capacitive touch with an I2C touch interface for responsive interaction.
Offers a 178° viewing angle for comfortable viewing from different positions.
Uses optical bonding and a 6H toughened glass panel for improved clarity and durability.
Supports Raspberry Pi 5, 4B, 3B+, and 3A+, with additional adapter requirements for selected Compute Module versions.
Supports refresh rates of up to 60Hz and software-controlled backlight brightness.

Bulk Order?

For Best Price Contact on WhatsApp for bulk discounts!
Or Fill the Form Below

Submit your Bulk Enquiry Here

First Name *

Last Name *

Email *

Phone *

+91

Company / Client

GST *

Materials List

File(s) size limit is 20MB. Max 3 files.

Choose Categories * (select one or more)

Select Categories

STEM Kits Development Boards Electronic Components Drone 3D Printers/Pens Sensors Batteries & Power Supply Tools & Instruments

Enter the Captcha *

Reload Captcha

Waveshare 10.1-Inch 1280×800 IPS Touchscreen LCD (c) Display for Raspberry Pi DSI Interface

~~Rs 13,499/-~~ Rs 8,739/-

Quantity:

Waveshare 10.1-Inch 1280×800 IPS Touchscreen LCD (c) Display for Raspberry Pi DSI Interface

~~Rs 13,499/-~~ Rs 8,739/-

Description
Specifications
Additional Resources
Warranty
Shipping & Return

Description

Waveshare 10.1-Inch 1280×800 IPS Touchscreen LCD (c) Display for Raspberry Pi DSI Interface

The Waveshare 10.1-Inch 1280×800 IPS Touchscreen LCD (C) is a versatile Raspberry Pi DSI display designed for projects that need a larger, interactive screen. It features a 10.1-inch IPS panel with a 1280 × 800 resolution, delivering full-color visuals with a wide 178° viewing angle. The display uses a DSI interface to connect directly to compatible Raspberry Pi boards and supports refresh rates of up to 60Hz.

Its 10-point capacitive touchscreen communicates through I2C, while the optical-bonded construction and 6H toughened glass provide clearer viewing and added durability. The display supports Raspberry Pi 5, Raspberry Pi 4B, Raspberry Pi 3B+, and Raspberry Pi 3A+, as well as selected Compute Module models with the appropriate adapter.

With software-controlled brightness, this 10.1-inch Raspberry Pi touchscreen display is well suited for interactive dashboards, smart home interfaces, control panels, kiosks, HMI projects, and other Raspberry Pi-based applications.

Features:

10.1-inch DSI touchscreen with ten-point capacitive touch control.
IPS display panel with hardware resolution of 1280×800.
Adopt the optical bonding technology for improved image quality.
Toughened glass touch panel (hardness up to 6H)
Support for Pi5/CM5/4B/CM4/3B+/3A+/3B/CM3+/CM3.
Directly drive the LCD using the Raspberry Pi's DSI interface, with a refresh rate of up to 60Hz.
Supports Bookworm, Bullseye, and Buster systems when working with Raspberry Pi.
Supports software control of backlight brightness.

Specifications

Package Includes:

1 x 10.1inch DSI LCD (C)
1 x FPC 15PIN 1.0 pitch 50mm (opposite sides)
1 x DSI-Cable-12cm
1 x FPC 15PIN 1.0 pitch 160mm (opposite sides)
1 x PH2.0 4PIN cable 200mm
1 x Screws pack

Specifications:

Specification	Details
Display Size	10.1 Inches
Display Type	IPS LCD
Resolution	1280 × 800 Pixels
Touchscreen	10-Point Capacitive Touch
Interface	DSI + I2C
Viewing Angle	178°
Refresh Rate	Up to 60Hz
Glass	6H Toughened Glass
Compatibility	Raspberry Pi 5, 4B, 3B+, 3A+
Applications	Raspberry Pi Projects, HMI, Kiosks & Control Panels
