Fractal Works Dragon 500 FDM 3D Printer
Fractal Works Dragon 500 FDM 3D Printer
Out of stock
Couldn't load pickup availability
BEST COUPON FOR YOU
When you shop for ₹ 20000 or more.Applicable on Checkout.
*Coupons are not applicable on Original Boards and Kits
- 500 x 400 x 400 mm build volume.
- 8 microns (X, Y) and 2 microns (Z) precision.
- Speeds up to 300 mm/s.
- Supports ABS, PLA, PETG, Polycarbonate, Carbon Fiber.
- Layer resolution from 100 to 800 microns.
- Nozzle up to 300°C.
- PEI FlexBuild surface for easy part removal.
- Remote monitoring via Wi-Fi and LAN.
- 150 kg weight for stability.
Fractal Works Dragon 500 FDM 3D Printer
The Dragon 500 FDM 3D Printer by Fractal Works offers a large 500 x 400 x 400 mm build volume and supports materials like ABS, PLA, PETG, Polycarbonate, Carbon Fiber, and more. With 8-micron (X, Y) and 2-micron (Z) precision, it delivers high accuracy and fast printing speeds up to 300 mm/s. The 3D printer features adjustable layer resolutions from 100 to 800 microns, a PEI FlexBuild surface for easy part removal, and remote monitoring via Wi-Fi and LAN. It is an excellent choice for high-quality, large-scale 3D printing tasks.
Features
- Large Build Volume: 500 x 400 x 400 mm for larger prints.
- High Precision: 8-micron (X, Y) and 2-micron (Z) positioning accuracy.
- Fast Printing: Speeds up to 300 mm/s.
- Versatile Material Support: Works with ABS, PLA, Tough PLA, PETG, PVA, Polycarbonate, Carbon Fiber Composites, CF Nylon.
- Adjustable Layer Resolution: 100–800 microns depending on nozzle size.
- High-Temperature Nozzle: Up to 300°C.
- PEI FlexBuild Surface: Ensures strong adhesion and easy part removal.
- Remote Monitoring: Camera for live updates via Wi-Fi and LAN.
- Durable Build: Weighs 150 kg for stability.
- Connectivity: Supports USB, Wi-Fi, Ethernet.
Package Includes
1 x Fractal Works Dragon 500 FDM 3D Printer
Specifications
| Specification | Details |
|---|---|
| Print Head | Fused Deposition Modeling (FDM) |
| Build Volume (Single) | 500 mm x 400 mm x 400 mm |
| Filament Diameter | 1.75 mm |
| XYZ Positioning Resolution | 8 Micron (X, Y), 2 Micron (Z) |
| Number of Extruders | 1 |
| Build Speed | Up to 300 mm/s |
| Layer Resolution | 0.4 mm nozzle: 100-300 micron 0.6 mm nozzle: 150-450 micron 0.8 mm nozzle: 200-600 micron 1.2 mm nozzle: 300-800 micron |
| Build Plate Temperature | Max: 150°C |
| Connectivity | USB port, WiFi, Ethernet |
| Supported Materials | ABS, PLA, Tough PLA, PLA+, PETG, PVA, PVA+, Polycarbonate, Carbon Fiber Composites, CF Nylon |
| Nozzle | Nozzle Temperature: Up to 300°C Positioning Accuracy Z: 10 um Positioning Accuracy X-Y: 15 um |
| Build Plate | PEI FlexBuild Surface |
| Monitoring | Camera over WiFi, LAN |
| Net Weight | 150 kg |
| Networking | Remote Monitoring System & Live Printer Updates |
