7Semi ILD213T Opto-Isolator Breakout Module
Let us know!
We'll try to match the price for you
We’ll notify you once the product is back in stock.
Couldn't load pickup availability
The 7Semi ILD213T Opto-Isolator Breakout is a compact signal isolation module designed to provide electrical isolation between two independent circuits. Built around the ILD213T opto-isolator, it uses an infrared LED and a phototransistor to transfer signals while maintaining electrical separation, helping reduce the effects of electrical noise, ground loops, and interference in electronic systems.
Designed for compatibility with a wide range of digital systems, the breakout operates from a 3.3V to 5V supply, making it suitable for use with common microcontrollers and embedded platforms. Its compact single-channel design integrates the infrared LED, phototransistor, and supporting circuitry into a small PCB that can be incorporated into prototype and production designs.
With a minimum isolation voltage of 2500Vrms and a response time of approximately 5 microseconds, the module is intended for applications requiring reliable signal isolation and fast switching. It can be used in industrial control systems, communication equipment, power supply circuits, and other applications where electrical isolation helps improve system reliability and signal integrity.
• Built around the ILD213T opto-isolator for reliable signal isolation.
• Uses an infrared LED and phototransistor for isolated signal transmission.
• Provides electrical isolation between two independent circuits.
• Operates from a 3.3V to 5V supply voltage.
• Offers a minimum isolation voltage of 2500Vrms.
• Delivers a fast response time of approximately 5 microseconds.
• Helps reduce the effects of electrical noise and interference.
• Assists in minimizing ground loop issues between connected circuits.
• Compact single-channel breakout board simplifies circuit integration.
• Suitable for industrial control and communication applications.
• Can be incorporated using through-hole or surface-mount soldering techniques.
• Designed for reliable signal isolation in embedded and electronic systems.
| Parameter | Value |
| Brand | 7Semi |
| Product Type | Opto-Isolator Breakout |
| Opto-Isolator | ILD213T |
| Channel | Single Channel |
| Input Device | Infrared LED |
| Output Device | Phototransistor |
| Supply Voltage | 3.3V to 5V |
| Minimum Isolation Voltage | 2500Vrms |
| Response Time | 5µs |
| Mounting | Through-hole or Surface-mount Soldering |
This product comes with a 6-month manufacturer warranty from the date of purchase, covering manufacturing defects only.
