Waveshare 800×480 5inch HDMI LCD (H) Capacitive Touch Screen
Waveshare 800×480 5inch HDMI LCD (H) Capacitive Touch Screen
Waveshare 800×480 5inch HDMI LCD (H) Capacitive Touch Screen
The Waveshare 800×480 5inch HDMI LCD (H) Capacitive Touch Screen is a compact and versatile touchscreen display designed for Raspberry Pi projects, embedded systems, mini PCs, and interactive applications. Its 5-inch 800 × 480 TFT display provides a practical viewing area, while the responsive 5-point capacitive touch screen makes it easy to interact with applications without requiring a separate input device.
The display supports HDMI and VGA connectivity, with USB used for touch control, making it suitable for Raspberry Pi, Jetson Nano, Windows PCs, and selected gaming consoles. The toughened glass touch panel offers up to 6H hardness, while the built-in OSD menu allows convenient brightness and contrast adjustment. It is a useful Raspberry Pi touchscreen display for dashboards, smart devices, robotics projects, portable computers, multimedia systems, and DIY electronics applications.
Features:
- The 5-inch capacitive touch screen has a hardware resolution of 800 × 480.
- 5-point capacitive touch control, tempered glass panel, and hardness of up to 6H.
- When working with a Raspberry Pi, it supports the Raspberry Pi OS, Ubuntu, Kali, and Retropie operating systems.
- When used as a computer monitor, it supports Windows 11/10/8.1/8/7 and ten-point touch.
- OSD menu in multiple languages, including power management, brightness/contrast adjustment, and so on.
- It features a 3.5mm audio connector and HDMI audio output.
Package Includes:
- 1 x 5inch HDMI LCD (H)
- 1 x HDMI cable
- 1 x HDMI to Micro HDMI Adapter
- 1 x USB type A plug to micro B plug cable
- 1 x RPi screws pack (4pcs)
Specifications:
| Specification | Details |
|---|---|
| Display Size | 5 inches |
| Resolution | 800 × 480 Pixels |
| Display Type | TFT LCD |
| Touch Type | Capacitive Touch |
| Touch Points | 5-Point Multi-Touch |
| Interface | HDMI / VGA / USB |
| Audio Output | 3.5 mm Jack |
| Viewing Angle | 178° |
| Touch Panel | Tempered Glass, up to 6H Hardness |
| Compatible Devices | Raspberry Pi, Jetson Nano, Windows PC, Gaming Consoles |
Warranty Coverage:
This product comes with a 1-year manufacturer warranty from the date of purchase, covering manufacturing defects only.
Warranty Void If:
The product shows signs of physical damage, mishandling, exposure to water/moisture, fire, natural calamities, unauthorized repairs, improper storage near heat or direct sunlight, or alteration in any way.
