Waveshare 5inch 800×480 Capacitive Touch DSI LCD Display for Raspberry Pi -Displays -LCD Displays -Robocraze

Waveshare FREE SHIPPING BEST PRICE GUARANTEED

Waveshare 5inch 800×480 Capacitive Touch DSI LCD Display for Raspberry Pi - Buy Online in India

Name: Waveshare 5inch 800×480 Capacitive Touch DSI LCD Display for Raspberry Pi
Brand: Robocraze
SKU: TIFDP0132
Price: 3829 INR
Availability: OutOfStock

Waveshare 5inch 800×480 Capacitive Touch DSI LCD Display for Raspberry Pi

Rs 3,829/-

- 37%

Rs 3,829/-

~~Rs 6,126/-~~

Save Rs 2,297/-

🪙

RC REWARDS Earn 38 RC Coins on this order

Incl. GST (No Hidden Charges)

Please hurry! Only 0 left in stock

We’ll notify you once the product is back in stock.

Quantity:

Free Delivery Above ₹999

Technical Support & Easy Returns

Same-Day Shipping (Order by 3 PM on Business Days)

Earn RC Coins on Every Prepaid Order

COD Available on Order Value Between ₹500 to ₹3,000

SKU: TIFDP0132

5-inch capacitive touch display with an 800 × 480 hardware resolution for Raspberry Pi projects.
Uses the DSI interface for direct connection to compatible Raspberry Pi boards.
Supports 5-point capacitive touch through an I2C touch interface.
Features a toughened glass touch panel with hardness up to 6H.
Supports up to a 60Hz refresh rate for smooth screen operation.
Compatible with Raspberry Pi 5, 4B, 3B+, 3A+, 3B, 2B, B+, A+, and selected Compute Module models.
Supports Raspberry Pi OS, Ubuntu, Kali, and RetroPie with driver-free operation.
Software-adjustable brightness helps provide flexible display control.

Bulk Order?

For Best Price Contact on WhatsApp for bulk discounts!
Or Fill the Form Below

Submit your Bulk Enquiry Here

First Name *

Last Name *

Email *

Phone *

+91

Company / Client

GST *

Materials List

File(s) size limit is 20MB. Max 3 files.

Choose Categories * (select one or more)

Select Categories

STEM Kits Development Boards Electronic Components Drone 3D Printers/Pens Sensors Batteries & Power Supply Tools & Instruments

Enter the Captcha *

Reload Captcha

Waveshare 5inch 800×480 Capacitive Touch DSI LCD Display for Raspberry Pi

~~Rs 6,126/-~~ Rs 3,829/-

Quantity:

Waveshare 5inch 800×480 Capacitive Touch DSI LCD Display for Raspberry Pi

~~Rs 6,126/-~~ Rs 3,829/-

Description
Specifications
Additional Resources
Warranty
Shipping & Return

Description

Waveshare 5inch 800×480 Capacitive Touch DSI LCD Display for Raspberry Pi

The Waveshare 5inch DSI LCD is a compact 800 × 480 capacitive touch display for Raspberry Pi, designed to provide a convenient touchscreen interface for embedded systems, DIY electronics, robotics, and Raspberry Pi projects. It uses the Raspberry Pi's DSI interface for direct display communication and supports up to 60Hz refresh rate.

The display features a 5-inch screen, 800 × 480 resolution, 5-point capacitive touch, and an I2C touch interface, while its toughened glass panel provides hardness up to 6H. The display supports Raspberry Pi 5, 4B, 3B+, 3A+, 3B, 2B, B+, and A+ models, along with selected Compute Module versions, and works with Raspberry Pi OS, Ubuntu, Kali, and RetroPie without requiring additional display drivers.

Brightness can also be adjusted through software, making it suitable for interactive dashboards, control panels, portable Raspberry Pi systems, smart home interfaces, and other touchscreen-based applications.

Features:

The hardware resolution for the 5-inch capacitive touch screen is 800 x 480.
The capacitive touch panel supports 5-point touch.
Toughened glass capacitive touch panel with hardness up to 6H.
Pi5/4B/CM4/3B+/3A+/3B/CM3/CM3+/2B/B+/A+ is compatible.
Directly drive the LCD with the Raspberry Pi's DSI interface at up to 60Hz refresh rate.
When dealing with Raspberry Pi, support the Raspberry Pi OS, Ubuntu, Kali, Volumio, and Retropie without the need for a driver.
When working with VisionFive 2, you can use Debian, single-point touch control, and without a driver.
Tinker Board 2 supports Linux/Android, five-point touch control, and is driver-free.
When using Core3566, support Debian/Ubuntu, five-point touch control, and driver-free.
Supports brightness adjustment via software.

Specifications

Package Includes:

1 x 5inch DSI LCD
1 x FPC 15PIN 1.0 pitch 50mm (opposite sides)
1 x DSI-Cable-12cm
1 x FPC 15PIN 1.0 pitch 160mm (opposite sides)
1 x Screws pack

Specifications:

Display Size	5 inch
Resolution	800 × 480 pixels
Display Interface	DSI
Touch Type	Capacitive
Touch Points	5-point
Touch Interface	I2C
Touch Panel	Toughened Glass
Glass Hardness	Up to 6H
Refresh Rate	Up to 60Hz
Brightness Control	Software adjustable
Weight	0.208 kg
