Wavesahre 2.4inch LCD Display Module 240×320 with 65K RGB

Wavesahre 2.4inch LCD Display Module 240×320 with 65K RGB

The 2.4inch LCD display module offers a brilliant 240×320 resolution screen with 65K RGB color support, making it perfect for students' electronics projects and small business applications.

This versatile display features the ILI9341 driver that works seamlessly with Arduino, Raspberry Pi, and other popular development boards through SPI interface. The module comes with a built-in SD card slot, allowing you to easily store and display images directly from storage.

Setting up this LCD module is straightforward with the comprehensive documentation and example codes provided. The display supports both 3.3V and 5V logic levels, eliminating the need for additional level shifters in most projects.

Its compact size (60.9mm × 42.0mm) makes it ideal for portable devices, educational demonstrations, and commercial products requiring a small but clear display. The module includes resistive touch functionality for interactive applications, enabling you to create touch-controlled interfaces for your projects.

Features:

• 240×320 resolution with 65K RGB colors for high-quality display
• Built-in ILI9341 controller for simplified programming
• SPI interface with speeds up to 32MHz for fast data transmission
• Resistive touch panel with XPT2046 touch controller
• SD card slot supporting FAT16/FAT32 file systems
• Operating voltage: 3.3V with 5V-tolerant IO pins

Package Includes:

• 1 x Wavesahre 2.4inch LCD Display Module 240×320 with 65K RGB

Specifications:
