Holybro PM06 V2 70A Power Module – 2S–14S - Buy Online in India

Holybro PM06 V2 70A Power Module – 2S–14S

Rs 2,869/-
- 28%
Rs 2,869/-
Rs 3,999/-
Save Rs 1,130/-
🪙
RC REWARDS Earn 28 RC Coins on this order
Incl. GST (No Hidden Charges)
Please hurry! Only 0 left in stock

We’ll notify you once the product is back in stock.

Free Delivery Above ₹999

Technical Support & Easy Returns

Same-Day Shipping (Order by 3 PM on Business Days)

Earn RC Coins on Every Prepaid Order

COD Available on Order Value Between ₹500 to ₹3,000
SKU: TIFC00440
  • Holybro PM06 V2 70A Power Module designed for 2S–14S LiPo battery systems.
  • Provides a clean 5.2V regulated power supply to the flight controller.
  • Measures battery voltage and current consumption through analog signals.
  • Features integrated power distribution for up to 4 ESCs.
  • Comes with pre-soldered XT60 connector, 12AWG wires, capacitor, and 6-pin JST-GH cable.
  • Suitable for Pixhawk-based drones, UAVs, and multirotor power systems.

Note: The pre-soldered XT60 connector and 12AWG wire are rated for 30A continuous and 60A burst current for under 60 seconds.

Bulk Order?

For Best Price Contact on WhatsApp for bulk discounts!
Or Fill the Form Below

Submit your Bulk Enquiry Here
+91

File(s) size limit is 20MB. Max 3 files.

Select Categories
CAPTCHA
Reload Captcha
Robocraze Academy Limited Time Offer
Holybro PM06 V2 70A Power Module – 2S–14S -Drone Parts -Drone Accessories -Robocraze
Holybro PM06 V2 70A Power Module – 2S–14S
Rs 3,999/- Rs 2,869/-
Holybro PM06 V2 70A Power Module – 2S–14S -Drone Parts -Drone Accessories -Robocraze
Holybro PM06 V2 70A Power Module – 2S–14S -Drone Parts -Drone Accessories -Robocraze
Holybro PM06 V2 70A Power Module – 2S–14S -Drone Parts -Drone Accessories -Robocraze
Holybro PM06 V2 70A Power Module – 2S–14S -Drone Parts -Drone Accessories -Robocraze

Holybro PM06 V2 70A Power Module – 2S–14S

Rs 3,999/- Rs 2,869/-
Description

Holybro PM06 V2 70A Power Module – 2S–14S

The Holybro PM06 V2 70A Power Module is a reliable power management solution for drones and UAVs using 2S to 14S LiPo batteries. It delivers a clean and regulated 5.2V output to the flight controller while providing analog measurements of battery voltage and current consumption through the included 6-pin JST-GH cable.

The module also integrates power distribution for up to four ESCs, helping simplify the wiring of multirotor power systems. It comes ready to install with a pre-soldered XT60 connector, 12AWG wires, and capacitor.

The pre-soldered XT60 and 12AWG wiring are rated for 30A continuous current and 60A burst current for less than 60 seconds; higher-current applications require an appropriately rated connector and wire size. Since the PM06 V2 uses analog data output, it is not compatible with Pixhawk 5X and Pixhawk 6X, which require a digital power module such as the PM02D.

Features:

  • Voltage Compatibility: Supports a wide input voltage range of 2S to 14S, making it suitable for a variety of applications.
  • Monitoring capabilities include real-time current consumption and battery voltage monitoring via a 6 pin JST-GH connection.
  • The PCB's continuous current rating of 70A and burst current rating of 120A (<60 seconds) assure reliable power distribution.
  • Efficient Power Distribution: Integrated power distribution for four ESCs makes wiring easier and improves energy transmission.
  • User-Friendly Design: Includes pre-soldered XT60 connection, wires, and capacitor for simple installation and increased stability.
  • Compact and Lightweight: The drone's compact size (35x35x5mm) and weight of 24g reduce its total weight impact.
  • The pre-soldered XT60 plug and 12AWG wire are rated for 30A continuous current and 60A burst current (<60 seconds).
Specifications

Package Includes:

  • 1 x PM06 Power Module
  • 1 x JST GHR 6pin 1.25mm pitch cable

Specifications:

Specification Details
Item Type Module
Input Voltage 2S–14S
PCB Continuous Current Rating 70A
PCB Burst Current Rating 120A (<60 sec)
Output DC 5.2V, 3A Max
Maximum Output Power 18W
Voltage Divider 18.182
Amperes per Volt 36.364
Dimensions (L × W × H) 35 × 35 × 5 mm
Mounting Hole Pattern 30.5 × 30.5 mm
Weight 24 g
