Fractal Works Dragon 700 FDM 3D Printer
Fractal Works Dragon 700 FDM 3D Printer
Out of stock
Couldn't load pickup availability
BEST COUPON FOR YOU
When you shop for ₹ 20000 or more.Applicable on Checkout.
*Coupons are not applicable on Original Boards and Kits
- 700 x 600 x 400 mm build volume.
- 8 microns (X, Y) and 2 microns (Z) accuracy.
- Print speeds up to 300 mm/s.
- Compatible with various materials.
- Adjustable layer resolution from 100 to 800 microns.
- Nozzle temperature up to 300°C.
- PEI FlexBuild surface for easy part removal.
- Remote monitoring via Wi-Fi and LAN.
- 200 kg weight for stability.
Fractal Works Dragon 700 FDM 3D Printer
Dragon 700 FDM 3D Printer by Fractal Works offers a large 700 x 600 x 400 mm build volume, supporting materials like ABS+, PLA+, PETG, and Carbon Fiber Composites. It features 8-micron (X, Y) and 2-micron (Z) accuracy for precise prints, with a single extruder that heats up to 300°C and prints at speeds up to 300 mm/s. Layer resolution is adjustable from 100 to 800 microns, and the PEI FlexBuild surface ensures easy part removal. With remote monitoring via Wi-Fi and LAN, it’s a durable, reliable choice for large-scale, high-quality 3D printing.
Key Features
- Large Build Volume: 700 x 600 x 400 mm.
- High Precision: 8 microns (X, Y) and 2 microns (Z).
- Print Speed: Up to 300 mm/s.
- Supports Multiple Materials: ABS+, PLA+, PETG, Polycarbonate, Carbon Fiber Composites, TPU.
- Adjustable Layer Resolution: 100 to 800 microns.
- Nozzle Temperature: Up to 300°C.
- PEI FlexBuild Surface: Easy part removal and strong adhesion.
- Remote Monitoring: Wi-Fi and LAN connectivity for live updates.
- Durable Design: Weighs 200 kg for stability.
Package Includes
1 x Fractal Works Dragon 700 FDM 3D Printer
Specifications
| Specification | Details |
|---|---|
| Print Head | Fused Deposition Modeling (FDM) |
| Build Volume (Single Mode) | 700 mm x 600 mm x 400 mm |
| Filament Diameter | 1.75 mm |
| XYZ Positioning Resolution | 8 Micron (X, Y), 2 Micron (Z) |
| Number of Extruders | 1 |
| Build Speed | Up to 300 mm/s |
| Layer Resolution | 0.4 mm nozzle: 100-300 micron 0.6 mm nozzle: 150-450 micron 0.8 mm nozzle: 200-600 micron 1.2 mm nozzle: 300-800 micron |
| Built Plate Temperature | Max: 150°C |
| Connectivity | USB port, WiFi, Ethernet |
| Supported Materials | ABS+, PLA+, PETG, PVA, PVA+, Polycarbonate, Carbon Fiber Composites, CF Nylon, TPU |
| Nozzle | Single Nozzle System |
| Nozzle Temperatures | Up to 300°C |
| Positioning Accuracy Z | 10 µm |
| Positioning Accuracy X-Y | 15 µm |
| Build Plate | PEI FlexBuild Surface |
| Monitoring | Camera over WiFi, LAN |
| Net Weight | 200 kg |
| Networking | Remote Monitoring System & Live Printer Updates |
