RS2205 2300KV Brushless DC Motor for FPV Racing Drone Black Cap (CW Motor Rotation) - RS2873/RS4665
RS2205 2300KV Brushless DC Motor for FPV Racing Drone Black Cap (CW Motor Rotation) - RS2873/RS4665
Couldn't load pickup availability
BEST COUPON FOR YOU
When you shop for ₹ 2500 or more.Applicable on Checkout.
*Coupons are not applicable on Original Boards and Kits
- It's a Lightweight Brushless DC Motor for FPV.
- Clockwise motor rotation.
- Up to 1024g thrust with 3s or 4s LiPo Battery.
- Cools by up to 30%.
- N52 magnets and Japanese NMB bearings.
- Factory-balanced.
- Fits 5mm-hole props with a 15mm shaft.
- Includes locknut and screws.
- High-purity copper windings.
RS2205 2300KV Brushless DC Motor for FPV Racing Drone CW Motor Rotation
If you want to give your FPV racing drone a real upgrade, then we have the perfect solution for you. Check out the latest RS2205 2300KV Brushless DC Motor for FPV — it's a game changer. It's lightweight, has a low center of gravity, and has some really high-quality components such as N52 magnets and authentic Japanese NMB bearings.
But what truly makes it stand out is the BLDC motor's cool self-cooling capability, which reduces the temperature by up to 30%. So, even when you push your drone to its limits, it remains cool and works excellently.
When combined with an 11.1v 5200mAh Bonka LiPo Battery with excellent propellers, this engine provides amazing acceleration and stopping power, with a thrust value of roughly 1024g. It is also compatible with 3-4S ESC, so it will easily fit into your existing configuration. If you are ready to take your drone to the next level then this medium price high-quality lightweight Brushless DC Motor for racing drones is the perfect solution.
Check out our collection of Top Quality Drone Motors.
Key Features:
- Innovative cooling design reduces motor temperature by up to 30%.
- Ensuring optimal performance during intense flights.
- Built with the highest grade N52 Neodymium magnets.
- Features genuine Japanese NMB bearings.
- Factory-balanced for smooth, stable flight.
- 15mm extended prop shaft fits most 5mm-hole props.
- Includes locknut and screws for 3mm and 4mm frames.
- High-purity copper windings for efficient power.
Package Includes:
1 x RS2205 2300KV Brushless DC Motor for FPV Racing Drone Black Cap
Specifications:
| Specification | Details |
|---|---|
| Model | RS2205 |
| Nut Type | CCW |
| Motor KV (RPM/V) | 2300 |
| Maximum Thrust (gm) | 1024 |
| Compatible LiPo Batteries | 3S ~ 4S |
| Framework | 12N14P |
| Shaft Diameter (mm) | 5 |
| Compatible Prop (inch) | 5 |
| Length (mm) | 27.9 |
| Width (mm) | 27.9 |
| Height (mm) | 31.7 |
| Weight (g) | 30 |
