- ESP32-C3, 160 MHz
- 1.28-inch IPS TFT, 240x240, 178° viewing angle
- Capacitive touch, fast response
- Custom buttons, Type-C, battery interface, UART for upgrades
- Supports Arduino IDE, Espressif IDF, Lua RTOS
- 42x42x9.8mm, 15g
- Ideal for DIY projects with custom UI support
CrowPanel ESP32-C3 1.28 inch Round IPS Display Capacitive Touch SPI Screen
The CrowPanel ESP32 Display features a 1.28-inch round screen powered by the ESP32-C3, which utilizes a 32-bit dual-core chip with a maximum clock speed of 160 MHz. It supports 2.4G WiFi and BLE low-power Bluetooth, making it suitable for IoT, smart home applications, and more.
With a 240x240 resolution, an IPS display, and a 178° viewing angle, this screen delivers vivid and clear images from any perspective. It offers capacitive touch functionality for smooth interaction, along with custom buttons like REST and BOOST, and allows for firmware upgrades via the UART serial port. The display is compatible with Arduino IDE, Espressif IDF, Lua RTOS, Home Assistant/PlatformIO/MicroPython, and the LVGL library, providing a flexible platform for DIY projects and custom UI design.
Features
- Powered by the ESP32-C3 master control with a 32-bit dual-core chip, offering a maximum clock frequency of 160 MHz.
- IPS display with a 178° wide viewing angle for more vibrant and detailed images.
- Capacitive touch for quick and responsive interactions.
- Includes custom, REST, and BOOT buttons, with a UART serial port for power supply and firmware upgrades.
- Compatible with various development platforms such as Arduino IDE, Espressif IDF, Lua RTOS, Home Assistant/PlatformIO/MicroPython, and supports the LVGL library.
Package Includes
1x ESP32 Display-1.28 inch Round Display (With Battery)
1x USB-A to USB-C Cable
Specification
| Specification | Details |
|---|---|
| Main Chip | ESP32-C3 |
| Processor | 32-bit RISC-V single-core processor, up to 160 MHz |
| Memory | 384 KB ROM, 400 KB SRAM (16 KB for cache), 8 KB SRAM in RTC |
| Size | 1.28 inch |
| Resolution | 240x240 |
| Signal Interface | SPI |
| Touch Type | Capacitive Touch |
| Panel Type | TFT LCD, IPS Panel |
| Color Depth | 262K |
| Brightness | 350 cd/m² |
| Viewing Angle | 178° |
| Button | Rest Button, Boot Button, Custom Button |
| Interface | Type-C Interface, Battery Interface |
| Encoder | With Button Function, Without Pin (Pin Size: 0.8mm*0.8mm) |
| Operation Power | Module: DC5V, Main Chip: 3.3V |
| Active Area | 32.51*32.51mm |
| Dimensions (LXWXH) | 9.1 X 10 X 3.8 cms |
| Weight | 52 gms |
