Anycubic Standard Resin Grey 1kg | High-Precision UV Resin for 3D Printing

Anycubic Standard Resin Grey is a beginner-friendly photopolymer resin designed for high-precision and reliable 3D printing. Its low-viscosity formulation provides smooth resin flow, fast bubble dissipation and efficient printing, while the 4.5–5.5% volume shrinkage rate helps maintain dimensional accuracy and reduce deformation. The resin offers strong build plate adhesion and is designed for easy model removal after printing. It produces smooth surfaces with fine details and a consistent grey finish, making it suitable for anime and game figurines, architectural models, appearance prototypes, structural prototypes and other general-purpose 3D printing applications. It is compatible with LCD and DLP 3D printers using 365–405nm UV light-curing technology and comes in a convenient 1kg bottle.

Features

• High-Precision Printing: Produces fine details, sharp edges and accurate model features for detailed 3D prints.
• Low Shrinkage: 4.5–5.5% volume shrinkage helps improve dimensional accuracy and reduce deformation.
• Smooth Resin Flow: Low viscosity of 200–230 mPa·s at 25°C supports smooth resin flow and efficient printing.
• Fast Bubble Dissipation: Helps reduce trapped bubbles for smoother surfaces and better detail reproduction.
• Strong Bed Adhesion: Provides reliable adhesion to the build plate during printing and easy model removal after printing.
• Smooth Surface Finish: Creates smooth printed surfaces suitable for painting and post-processing.
• LCD & DLP Compatibility: Works with compatible LCD and DLP 3D printers using 365–405nm UV light.
• Low-Odor Formulation: Formulated with low odor for a more comfortable printing experience.
• Grey Color: Grey (#7E93A7) provides a neutral finish suitable for models, prototypes and post-processing.
• Wide Applications: Suitable for figurines, architectural models, appearance prototypes, structural prototypes and general 3D printing.

Instructions for Use

1. Before Use

• Shake the resin bottle thoroughly before pouring.

• Clean the resin tank and build plate to remove dust, cured resin or other contaminants.

• Ensure the bottom of the resin tank is clean and highly transparent.

• Check that the release film is clean and free from damage.

• Confirm that the printer's printing parameters are correctly set for the resin.

• Maintain a recommended printing environment of 20–35°C to help prevent temperature-related printing failures.

2. During Use

• Unscrew the bottle cap and carefully remove the sealing film.

• Pour the required amount of resin into the resin tank.

• Do not exceed the maximum fill line of the resin tank.

• Avoid splashing or spilling resin during handling.

3. After Printing

Use suitable tools and materials for post-processing:

• Scraper for removing printed models from the build plate

• Flush cutters for removing supports

• Tweezers for handling small parts and supports

• Nitrile gloves for safe handling

• ≥95% IPA or suitable resin cleaning solution for cleaning printed models

4. Post-Processing

A. Remove the Model:
Use a scraper to carefully remove the printed model from the build plate, then remove the support structures using suitable tools.

B. Clean the Model:
Wash the printed model in an Anycubic Wash & Cure machine for approximately 10 minutes. Use ≥95% alcohol or a suitable resin cleaner.

C. Dry the Model:
Allow the model to air-dry, blow-dry it, or use a drying chamber. Proper drying helps prevent water absorption and potential cracking.

D. Secondary Curing:
Place the cleaned and dried model under suitable UV curing conditions and cure for approximately 3–5 minutes.

E. Recycle Unused Resin:
Filter unused resin through a 100-mesh sieve before returning it to storage or reusing it. This helps remove cured particles and other contaminants.

Precautions

• Storage: Store the resin at room temperature and keep it away from direct light.

• Recommended Temperature: Use the resin above 20°C. Low temperatures may reduce printing success, while higher temperatures can accelerate pigment settling.

• Pigment Settling: If pigment settles at the bottom, stir the resin with a plastic scraper or shake the bottle thoroughly before use.

• Light Protection: Resin cures when exposed to sunlight. Use the printer in a dim, ventilated area or keep the printer covered when not in use.

• Post-Printing Care: Remove printed models promptly after washing to help maintain their intended properties.

• Personal Protection: Always wear nitrile gloves and protective goggles when handling liquid resin. Avoid direct contact with skin and eyes.

• Waste Disposal: Fully cure leftover liquid resin before disposing of it as solid waste. Follow applicable local waste-disposal requirements.

• Ventilation: Maintain adequate ventilation while handling and printing with resin.

• Keep Away From Children & Pets: Keep liquid resin away from children, pets and pregnant women.
