7Semi SHT40 Temperature & Humidity Sensor Breakout I2C Qwiic SHT40 Breakout
Couldn't load pickup availability
The 7Semi SHT40 Temperature & Humidity Sensor Breakout (I2C Qwiic) is a compact and reliable sensor module designed to measure both temperature and humidity with high accuracy. It is based on the Sensirion SHT40 sensor, making it suitable for modern electronics projects that need precise environmental data.
This breakout board supports I2C communication and comes with a Qwiic connector, allowing quick and solder-free connections with microcontrollers like Arduino, ESP32, and Raspberry Pi. Its small size and low power consumption make it ideal for IoT devices, weather monitoring, indoor air quality projects, and learning applications where simplicity and accuracy matter.
| Operating Voltage | 3.3V – 5V |
|---|---|
| Operating Current | 0.45 mA |
| Interface | I2C |
| Response Time | 8 s (τ63%) |
| Humidity Measurement Range | 0 – 100% RH |
| Humidity Measurement Accuracy | ±1.8% RH |
| Temperature Measurement Range | -40°C to +125°C |
| Temperature Measurement Accuracy | ±0.2°C |
| Board Size | 30 × 22 mm |
