- This is the 150 RPM single shaft BO motor
- This BO motor capability to absorb shock and vibration as a result of elastic compliance.
- This BO motor ability to operate with minimum or no lubrication, due to inherent lubricity.
- The relatively low coefficient of friction.
- The Operating Voltage is 3V to 12V
- Rated Speed(After Reduction): 150 RPM
- This single-shaft BO motor is lightweight
150 RPM Single Shaft BO Motor
This is the 150 rpm straight single shaft BO motor, which gives good torque and rpm at lower operating voltages, It is the biggest advantage of these BO motors. Small shaft with matching wheels gives an optimized design for your application or robot. Mounting holes on the body & light weight makes it suitable for in-circuit placement.
This BO motor is the low-cost geared DC Motor. It is an alternative to our metal gear DC motors. It comes with an operating voltage of 3-12V and is perfect for building small and medium robots. This BO motor is ideal for DIY enthusiasts. This motor set is inexpensive, small, easy to install, and ideally suited for use in a mobile robot car. If you want to use this 150 rpm straight single shaft BO motor in your projects , for that you will need few essential components like batteries , switches , wires , soldering tools and wheels.
Features:
- Cost-effectiveness of the injection-molding process.
- Elimination of machining operations.
- Low density: lightweight, low inertia.
- Uniformity of parts.
- Capability to absorb shock and vibration as a result of elastic compliance.
- Ability to operate with minimum or no lubrication, due to inherent lubricity.
- The relatively low coefficient of friction.
- Corrosion-resistance; elimination of plating, or protective coatings.
- The quietness of operation.
- Tolerances often less critical than for metal gears, due in part to their greater resilience.
Package Includes:
- 1 x 150 RPM Single Shaft BO Motor
Specifications:
|
Operating Voltage (VDC) |
3V - 12V |
|
Shaft Length (mm) |
8.5 |
|
Shaft Diameter (mm) |
5.5 |
|
No Load Current (mA) |
40-180mA. |
|
Rated Speed After Reduction (RPM) |
150 |
|
Rated Torque (Kg-Cm) |
0.35 |
|
Weight (gm) |
30 |
|
Dimensions in mm (LxWxH) |
55 x 48 x 23 mm |
Shipping & Returns
Shipping & Returns
- All orders confirmed before 3 pm IST are shipped on the
same day, barring rare pickup delays on holidays or disturbances - Delivery time in Metro cities is 1-3 days, Others it is
3-7 days. It varies based on location, reliant on courier services - Return window: 7 days from receipt unless stated
otherwise. No refunds/replacements after - Returns only for non-working/damaged products are accepted
- Initiate return requests to our customer service team via Support ticket or contact us at +91-8123057137
- Refunds are processed within 3-4 working days post inspection and approval.
For more details, please check our Shipping and Return Policy
People Also Buy
Red BO Motor Wheel +100 RPM Single Shaft BO Motor - Set of 2
Regular price
Rs. 114
Regular price
Rs. 169
Sale price
Rs. 114
Unit price
per
Incl. GST (No Hidden Charges)
Sold out
DIY D2-1 Intelligent Line follower/Tracing Car Kit
Regular price
Rs. 209
Regular price
Rs. 249
Sale price
Rs. 209
Unit price
per
Incl. GST (No Hidden Charges)
Sale
4WD Four Wheel Drive Kit - A Smart Robot Car with Chassis
Regular price
Rs. 499
Regular price
Rs. 741
Sale price
Rs. 499
Unit price
per
Incl. GST (No Hidden Charges)
Sold out
Found a better price?
Let us know!
We'll try to match the price for you
1. What is a BO Motor?
- Bo motor (Battery Operated) is a lightweight DC geared motor that produces high torque and rpm at low voltages. When powered by a single Li-Ion cell, this motor can reach speeds of around 150rpm. Excellent for battery-powered lightweight robots.
2. What are the features of the 150RPM BO Motor?
- At lower operating voltages, the 150RPM BO motor provides good torque and rpm. The small shaft combined with matching wheels results in an optimized design for your application or robot. Because of the mounting holes on the body and the lightweight, it is suitable for in-circuit placement. From 3V to 12V, the motor runs smoothly and provides a wide range of RPM and torque.
3. Where can I use 150 RPM BO Motor?
- The 150RPM BO Motors are (Battery Operated) motors used in smart robot cars, DIY trains, obstacle avoider robots, 2wd robots, and other applications. BO motors are used in hobby-grade projects where a small DC motor is needed as a simple actuator.
