Smart Plant Monitoring System

The Smart Plant Monitoring System is a game-changer for plant enthusiasts and farmers alike. This blog provides an informative overview of the purpose, advantages, and implementation of this innovative system. By leveraging advanced technology, such as sensors and IoT connectivity, this system enables users to monitor and care for their plants with precision. The blog delves into the advantages of this system, including real-time data analysis and remote plant management. It also discusses the process of building a prototype, complete with a circuit diagram and code snippets. By exploring the method and working of the project, readers gain valuable insights into this cutting-edge plant monitoring solution.

In recent years, we have seen a tremendous growth in the usage of smart technologies to monitor plant growth and their health. A smart plant monitoring system uses advanced sensors, machine learning algorithms, and the Internet of Things (IoT) to collect real-time data on different aspects of a plant's environment and growth. This breathtaking technology enables farmers, horticulturists, and researchers to better understand the needs of plants, optimize their growth conditions, and detect early signs of disease or stress. These systems have the ability to monitor and control the growth of plant remotely anytime. With these features, we can say that smart plant monitoring system is indeed an efficient and sustainable approach in the field of agriculture.

In this tutorial, we will enrich ourselves with the details of smart plant monitoring systems, discussing their purpose, components, working, advantages over traditional systems, and other important aspects of this emerging technology.

Purpose of the system

The primary purpose of a smart plant monitoring system is to collect and analyze data related to the growth and health of plants. This system can provide real-time information on environmental factors such as temperature, humidity, light intensity, soil moisture, and nutrient levels, which can have a significant impact on the growth of plants. By tracking these variables, smart plant monitoring systems allow us to make quick and informed decisions about the amount and timing of water and fertilizer applications, adjust the lighting or temperature, and take preventative measures to control pests and diseases.

Another critical purpose of the system is to detect early signs of plant stress or disease. The system can alert the people in charge about the issues such as nutrient deficiencies, water stress, or pest infestations, allowing them to take immediate actions before the problem worsens. This capability not only helps to reduce the risk of crop loss but also promotes more sustainable practices by minimizing the use of pesticides and fertilizers.

Overall, the main goal of the system is to optimize plant growth and health while reducing waste and maximizing yields. By providing precise and timely information, this technology can help farmers, plant-enthusiasts and researchers to achieve more sustainable and efficient plant production practices.

Advantages :

There are numerous advantages of this system. The important ones are pointed below:

  • Increased efficiency: The real-time data about plant growth and environmental conditions can help to optimize the use of resources needed for the system such as water, energy, fertilisers, soil etc. This will lead to cut-costs and increase the savings. Also, this is proven to be a very sustainable approach for plant production.
  • Better plant health: By detecting early signs of stress or disease, smart systems can aid to maintain and monitor healthier plants, which leads to higher yields and increase in the quality of the production. The need for chemical treatments is reduced dramatically thereby improving food safety and sustainability of environment
  • More precise and targeted interventions: Smart plant monitoring systems enable us to make more informed and intelligent decisions about when and how to perform treatments such as fertilizers or pesticides. This can reduce waste and minimize the risk of over-applying chemicals, which can be harmful to the environment and human health.
  • Remote monitoring and control: Remote monitoring helps us to maintain the health of the crops and make amendments from any corner of the world if we happen to have an internet connectivity. This method helps us to save our immense amount of time and reduce labour cost hugely.
  • Improved data collection and analysis: These data provide valuable insights into the growth of plant and their environmental conditions which otherwise would be difficult enough without the involvement of Iot and sensors. Manually collecting these data for analysis is an exhausting task to achieve. This method helps researchers to develop new strategies for improving the production of plant and making their monitoring easier.

Building a prototype:

Component Required for Smart Plant Monitoring are given below

Project Hardware Used

Project Software Used

  • Arduino IDE(for programming the ESP8266 board)
  • Blynk App(for IoT control and wireless monitoring).

Circuit Diagram

The soil moisture sensor is attached to the NodeMCU's A0 analog pin. The NodeMCU's D4 pin (Digital pin) is linked to the signal pin of the DHT Temperature and Humidity sensor. The NodeMCU's D5 pin is used to connect the relay module. The water pump is further linked to the engine. The NodeMCU's D3 pin is linked to the LED. This serves as a source of illumination at night for IoT-controlled nighttime operations.

The NodeMCU always receives an analog signal from the DHT and moisture sensors, which it then uses to verify the temperature, humidity, and moisture levels.

Code:



#define BLYNK_PRINT Serial

#include <SPI.h>

#include <ESP8266WiFi.h>

#include <BlynkSimpleEsp8266.h>

#include <SimpleTimer.h>

#include <DHT.h>

#define BLYNK_PRINT Serial

#include <OneWire.h>

#include <DallasTemperature.h>

#define ONE_WIRE_BUS D2

OneWire oneWire(ONE_WIRE_BUS);

DallasTemperature sensors(&oneWire);



char auth[] ="----------------";               //Authentication code sent by Blynk

char ssid[] = "-------";                       //WiFi SSID

char pass[] = "-------";                       //WiFi Password



#define sensorPin D3

int sensorState = 0;

int lastState = 0;

#define DHTPIN 2

#define DHTTYPE DHT11

DHT dht(DHTPIN, DHTTYPE);

SimpleTimer timer;

void sendSensor()

{

  float h = dht.readHumidity();

  float t = dht.readTemperature();



  if (isnan(h) || isnan(t)) {

    Serial.println("Failed to read from DHT sensor!");

    return;

  }



  Blynk.virtualWrite(V5, h);  //V5 is for Humidity

  Blynk.virtualWrite(V6, t);  //V6 is for Temperature

}

void setup()

{

  Serial.begin(9600);

  Blynk.begin(auth, ssid, pass);

   pinMode(sensorPin, INPUT);

  dht.begin();



  timer.setInterval(1000L, sendSensor);

  Serial.begin(115200);

  Blynk.begin(auth, ssid, pass);

   sensors.begin();

}

int sensor=0;

void sendTemps()

{

sensor=analogRead(A0);

sensors.requestTemperatures();

float temp = sensors.getTempCByIndex(0);

Serial.println(temp);

Serial.println(sensor);

Blynk.virtualWrite(V1, temp);

Blynk.virtualWrite(V2,sensor);

delay(1000);

}

void loop()

{

  Blynk.run();

  timer.run();

  sendTemps();

  sensorState = digitalRead(sensorPin);

Serial.println(sensorState);



if (sensorState == 1 && lastState == 0) {

  Serial.println("needs water, send notification");

  Blynk.notify("Water your plants");

  lastState = 1;

  delay(1000);

//send notification



  }

  else if (sensorState == 1 && lastState == 1) {

    //do nothing, has not been watered yet

  Serial.println("has not been watered yet");

  delay(1000);

  }

  else {

    //st

    Serial.println("does not need water");

    lastState = 0;

    delay(1000);

  }



  delay(100);

}

Method:

  • The components should be connected as shown in the circuit diagram
  • Download Blynk App on your Smartphone and click new project.
  • Select the NodeMcu board and click on create.
  • Add three gauges for display (temp, humidity and soil moisture)
  • Soil moisture – Virtual 2 pin (V2) , value : 0-200 and set it on 1 second and do the same for temperature(V6) and humidity(V5) as well.
  • Add a button and a timer.
  • Navigate to the settings of the button and rename it as ‘Water’. Select digital pin 0 (D0) and select switch (slide the point to switch from push)
  • Go to the settings of the timer and select D0. We can set the on and off time for the motor i.e the relay.
  • Upload the code on the board after selecting the correct board and port on the Arduino IDE.

Working of the project

The main agenda of the system is to automate the process of monitoring and watering plants with the help of various sensors and microcontroller. The system uses NodeMCU ESP8266, which acts as the main controller and connects to Wi-Fi which enable remote monitoring. The soil moisture sensor measures the moisture level of the soil and it also helps us to determine if the plant needs watering or any other aid. The temperature and humidity sensors are used to measure the environmental conditions which is quite obvious from the names. These factors are equally important for the growth of the plant. The relay module is used to control the water pump and it ensures that the plant receives sufficient amount of water for their growth.

The system continuously monitors the moisture level of the soil using the soil moisture sensor as stated above. If the moisture level goes down below a certain threshold, the NodeMCU ESP8266 immediately sends a signal to the relay module to activate the water pump. As a response, the water pump then supplies the needed amount of water to the plant.

In addition to this, the NodeMCU ESP8266 sends real-time data to a mobile or web application , allowing users to observe the plant's health and adjust the settings remotely (provided they have an internet connection with them). The user can set the moisture threshold, temperature, and humidity levels according to the plant's requirements.

Overall, the Smart Plant Monitoring System automates the process of monitoring and watering plants, making it easier for users to supervise of their plants. This system provides several advantages such as efficient water usage, real-time monitoring, remote access, and customized settings.

Conclusion

Smart plant monitoring systems are a revolutionary approach to optimize plant growth and improve overall crop yield and plant growth. With the use of NodeMCU ESP8266, soil moisture sensors, temperature and humidity sensors, relay modules, and water pumps, this system can effectively monitor and regulate the environmental factors that are crucial for plant growth. The benefits of this technology are myriad, including reduced water waste, increased crop yield, and improved resource management. The potentiality to remotely monitor, observe and control the plant growth environment is a game-changer in the agricultural industry and provides farmers with the necessary tools to optimize their crop growth while reducing the quantity of resources used without compromising with the quality even a bit. The implementation of smart plant monitoring systems is a step towards sustainable agriculture and has the potential to positively impact the environment, economy, and society as a whole.



If you appreciate our work don't forget to share this post and leave your opinion in the comment box.



Please do check out other blog posts about Popular electronics



Make sure you check out our wide range of products and collections (we offer some exciting deals!)

Frequently Asked Questions

1. What is smart plant monitoring system?

A smart plant monitoring system is a system that uses sensors and IoT technology to monitor and control the health of plants. The system collects and evaluates data regarding changing weather and soil moisture levels before sending timely warnings to the user’s phone
The aim of making plant monitoring systems smart is to use automation and IoT technology to maintain the plant’s proper growth and health
The system can monitor and control the shade, temperature, humidity, light intensity, and soil moisture, all of which have effects on plant health
The system can also provide climate/irritant readings to develop a sync & start smart irrigation system
The system can be made using an Arduino board/ESP32 and a set of sensors that acquire information and then send it to the cloud using an IoT cloud platform. The system can also have an automatic watering system that monitors and maintains the approximate moisture content in soil, which avoids over/under irrigation. The smart plant monitoring system is a low-cost system whose basic use is for household purposes

2. What are the advantages of smart plant monitoring system using IOT?

Smart plant monitoring systems using IoT have several advantages, including:

  • Optimized water usage: Smart plant monitoring systems can optimize water levels based on soil moisture and weather predictions, which can help avoid over/under irrigation and conserve water
  • Increased production: Smart agriculture solutions can increase production by providing real-time data and production insights, which can help farmers make informed decisions about their crops
  • Lowered operation costs: IoT-based smart agriculture solutions can help lower operation costs by providing data insights and process automation through low-cost sensors and IoT platform implementation
  • Equipment monitoring: Farming equipment can be monitored and maintained according to production rates, labor effectiveness, and failure prediction, which can help improve efficiency and reduce costs
  • Improved accuracy: Smart plant monitoring systems can improve accuracy in monitoring plant growth and health, which can help farmers make informed decisions about their crops
  • Less time consumption: Using IoT-based smart plant monitoring systems can reduce the time required for monitoring and maintenance, which can help farmers save time and focus on other important tasks
  • Cost reduction: Smart plant monitoring systems can be low-cost, making them accessible to small-scale farmers who may not have the resources for traditional monitoring methods

3. What is the plant monitoring system using ESP32?

A plant monitoring system using ESP32 is a device that can measure and monitor various parameters of a plant's environment, such as soil moisture level, humidity level, temperature, and the "feels-like" temperature.
The system can be controlled automatically by the ESP32, which can control a water pump based on the soil moisture level
The soil moisture sensor is a simple analog 3-pin device that measures the voltage output of the soil, which decreases with moisture
The system can be connected to the Blynk IoT app, which allows the user to monitor and control the plant's environment from anywhere in the world. The ESP32 can also be used to read the value from a capacitive moisture sensor and determine if the soil is wet or dry. Calibration is required to determine the value at which the soil changes its moisture from dry to wet. The system can be built using an ESP32 board, a micro USB cable, and a capacitive soil moisture sensor
