20A ACS712 Current Sensor

Rs. 85
Rs. 124
Rs. 85
Save Rs. 39
(-31%)
Incl. GST (No Hidden Charges) Found a better price?
Please hurry! Only 8 left in stock
SKU: TIFSS0197
  • Low-noise analog signal path
  • 5 µs output rise time in response to step input current
  • Small footprint, low-profile SOIC8 package
  • 2.1 kVRMS minimum isolation voltage from pins 1-4 to pins 5-8
  • Supply Voltage: 4.5V~5.5V DC
  • Measure Current Range: 20A
  • Sensitivity: 100 mV/A
FLAT ₹ 100/- OFF
RC100
COPY CODE

When you shop for ₹2500 or more. Applicable at checkout.
*Coupons are not applicable on Original Boards and Kits.

Free shipping on Orders Above Rs 499/-

Technical Support & Easy Returns

Same Day Shipping

Earn RC Coins on Every Purchase

Cash on Delivery Available

Robocraze Academy Limited Time Offer

Bulk Order?

For Best Price Contact on WhatsApp for bulk discounts!
Or Fill the Form Below

Submit your Bulk Enquiry Here
Enter the Captcha
Reload
Robocraze Academy Limited Time Offer
20A ACS712 Current Sensor - High-precision current sensing up to 20A. -Current Sensor -Robocraze
20A ACS712 Current Sensor
Rs. 124 Rs. 85
20A ACS712 Current Sensor - High-precision current sensing up to 20A. -Current Sensor -Robocraze
20A ACS712 Current Sensor - High-precision current sensing up to 20A. -Current Sensor -Robocraze
20A ACS712 Current Sensor - High-precision current sensing up to 20A. -Current Sensor -Robocraze
20A ACS712 Current Sensor - High-precision current sensing up to 20A. -Current Sensor -Robocraze
20A ACS712 Current Sensor - High-precision current sensing up to 20A. -Current Sensor -Robocraze

20A ACS712 Current Sensor

Rs. 124 Rs. 85
Description

20A ACS712 Current Sensor

The 20A ACS712 Range Current Sensor Module ACS712 consists of a precise, low-offset, linear Hall circuit with a copper conduction path located near the surface of the die. Applied current flowing through this copper conduction path generates a magnetic field in which the Hall IC converts into a proportional voltage.

Sensing and controlling current flow is a fundamental requirement in a wide variety of applications including, over-current protection circuits, battery chargers, switching mode power supplies, digital watt meters, programmable current sources, etc.

Connection Diagram of Arduino Uno with Current Sensor :

Interfacing a current sensor with Arduino uno

Fig: Connection of ACS712 Current Sensor with Arduino UNO

Curve of relation between the DC input voltage and measuring current:

Fig: Output Voltage vs. Sensed Voltage

Features:

  • Hall Effect-Based Sensor: Utilizes the Hall effect for current measurement, providing electrical isolation.
  • Analog Voltage Output: Produces an analog voltage proportional to the current passing through the sensor.
  • High Accuracy: Offers precise current measurement with low offset and linear output.
  • Wide Measurement Range: Can measure currents from -20A to +20A.
  • Sensitivity: 100mV/A, meaning the output voltage changes by 100mV for every ampere of current.
  • Supply Voltage: Operates at 5V.
  • Compact Size: Dimensions are typically around 32x15mm

Applications:

  • Power Monitoring: Used to monitor power consumption in various devices and systems.
  • Battery Management Systems: Measures current flow in battery-operated systems to ensure proper charging and discharging.
  • Motor Control: Provides precise current measurement for controlling motors in various applications.
  • Overcurrent Protection: Detects overcurrent conditions to protect circuits from damage.
  • Inverters and SMPS: Used in inverters and switch-mode power supplies (SMPS) for current measurement and control.
  • Electric Vehicle Charging Stations: Monitors and controls current in high-power charging stations.
  • Heavy Machinery: Measures current in heavy machinery for performance analysis and maintenance.
  • Automotive Applications: Used in automotive systems like power steering and inverters.
Specifications

Package Includes:

  • 1 x 20A ACS712 Current Sensor

Specifications:

Sensitivity 100mV/A
Measure Current Range 20A
Supply Voltage 4.5V~5.5V DC
Dimensions  5 x 4 x 3cms
Weight 5 grams
Additional Resources
FAQ

1. What is current sensor ACS712?

  • The ACS712 is a current sensor that can work in both AC and DC modes. This sensor runs on 5V and outputs an analog voltage proportional to the measured current. This tool is made up of a series of precision Hall sensors connected by copper lines.

2. Can ACS712 measure AC current?

  • The ACS712 current sensing module includes the ACS712 IC, which uses the Hall Effect principle to measure DC/AC current. It is simple to use with microcontrollers like Arduino because it only has three pins, two of which are power supply pins and the other is an analog output pin.

3. How use ACS712 current sensor with Arduino?

  • The ASC712 Current Sensor Module board's screw terminals are linked in series with the motor and power supply. Then connect the VCC, GND, and OUT of the ASC712 board to +5V, GND, and A0 of Arduino. Now, in order to view the results, a 16×2 LCD is connected to Arduino.

4. What is the purpose of current sensor?

  • A current sensor is a device that detects and converts current to a measurable output voltage proportional to the current flowing through the measured path. There are many different types of sensors, and each one is designed for a specific current range and environmental condition.
