40 AMP ESC - Yellow
40 AMP ESC - Yellow
Low stock: 9 left
Couldn't load pickup availability
Contact form
- Fast and precise motor control: ESC 40A delivers swift response for enhanced flight performance.
- Quadcopter optimized: Tailored design ensures optimal functionality for quadcopters.
- Stable power supply: Onboard BEC provides reliable 5V power for flight controller and modules.
- Versatile: Drives motors up to 40A and works with 2S-3S LiPo batteries.
- Wide compatibility: Works with various brushless motors within the 2S-3S LiPo range.
- Advanced technology: Features cutting-edge BLDC ESC for superior performance.
- Durable and reliable: High-quality construction ensures robust speed control.
40 AMP ESC - Yellow
Brushless Motor ESC is the perfect solution for drone enthusiasts and hobbyists. It excels in providing better flight control with its advanced BLDC technology. Crafted with top-quality materials, this speed controller ensures durability and optimal performance under ideal conditions. Suitable for motors consuming up to 40A current, it works on 2S-3S LiPo batteries and includes an onboard BEC for regulated 5V power.
Brushless Motor ESC is not just a speed controller; it's a key component for endless possibilities in the world of drones. Made for ease of use and maintenance, it is the ideal choice for both beginners and experienced users. Add it to your cart now and experience the difference!
Features:
- High quality brushless BEC replacement parts
- Excellent output ability of continues current of 40A
- Premium material made, stable and reliable
- Durable, Speed Controller, 40A, Universal
- Ideal speed controller for RC/FPV/Quadcopter/RC Airplanes and others
- Low resistance
- Sixteen cells Max (with BEC disabled)
- User programmable brake
- Low voltage auto setting based on battery
- Throttle range self-adjusting
- Soft start ramp up
- Auto motor cutoff with reset
- Runs motor in forward or reverse
- Safe power arming program ensures motor will not run accidentally after turn on
- Low torque start
- Auto shut down when signal is lost
Package Includes:
- 1 x 40 AMP ESC - Yellow
Specifications:
| Type | 40A Brushless Without BEC (short) |
| Material | Plastic |
| Continuous Output Current | 40A |
| Max Current | 50A (No Less than 10 Seconds) |
| DC Input Voltage | 3.7V-12.8V |
| BEC Output | 3A / 5V (Switch) |
| Size | 45mm x 26mm x 10mm |
| Ni-Mh/Ni-cd Compatibility | c4-10Ni- MH |
| Color | Yellow |
| Net Weight | 31g |
| Maximum Speed | 2-pole Motor 210000rpm |
| 6-pole Motor 70000rpm | |
| 12-pole Motor 35000rpm |
